KEM-TRON TECHNOLOGIES PVT. LTD. VADODARA, Gujarat

We are offering shale shakers. Removing solids from drilling fluid is fundamental to drilling performance. Solids control has a wide range of benefits, including but not limited to: increased drilling penetration, reduction in mud costs, reduction in disposal costs, and increased bit life. By and large, increased solids removal equates to lower drilling costs for the operator. shale shakers are the first line of defense for a properly designed solids control system. Shakers have been used on drilling rigs since the 1940’s and are a significant part of the drilling process. Shale shakers work by removing solids from drilling fluid as the mud passes over the surface of a vibrating screen. The liquid portion of the mud and solids pass through the screen while larger solids fall off the back end and are thus discarded. Drilling fluids are a key aspect of the drilling process and often lubricate & cool the drill bit and take drilled cuttings from the borehole. Shakers still remain the backbone of any solids control system. As time has progressed, so have these technologies; more advanced and efficient designs have been cultivated including screen technology. for more than 25 years, elgin has manufactured effective solids control and waste management equipment. elgin’s driving principal is to provide quality, dependable equipment. elgin is an original equipment manufacturer (oem) of shaker screens focused on today’s drilling contractor needs. Cleaner mud, increased productivity and screen life are key to any drilling operation. elgin’s screens deliver effective solids control with precise api 13c cut point and conductance.

We offer Decanter Centrifuge. Decanter Centrifuge ESS-1967HD2 Barite Recovery & Dewatering Centrifuge Whether you are working toward maximizing barite recovery or looking to get the most out of your “zero-discharge” closed-loop system, Elgin’s field proven decanter centrifuges are a perfect choice. With over 500 centrifuges installed worldwide, the ESS-1967HD2 represents Elgin’s flagship decanter centrifuge. Power and Performance Elgin’s ESS-1967HD2 Decanter Centrifuge is fitted with a NEMA premium, continuous duty, energy-efficient, poly-chain driven, 125 hp main drive and a direct-coupled 40 hp back-drive. The 125 hp main drive can operate the centrifuge up to a maximum rotational speed of 3, 100 rpm, therefore generating more than 2, 500 G’s of force. Using an inclined motor mount, motor and belt maintenance is made easy by the adjustment of two jack screws. No additional motor mounts, brackets or tensioning devices are required. By utilizing a carbon fiber poly-chain, no belt retensioning is required after installation is complete. The carbon fiber tensile cords are length-stable and can withstand shock loads that frequently lead to belt failure. More importantly, Elgin’s carbon fiber poly-chain will not require quarterly replacement.

we offer Vacuum Degassers. The vacuum degasser, also known as a mudgas separator is one of the first units of solids control equipment arranged to treat drilling mud. As such, they process all of the drilling mud from the flow line before the mud reaches the primary shale shakers. The units have no moving parts and rely on the density difference between the gas and the mud for removal. The process is simple, yet very effective for well drilling fluids processing system.

We offer Jet Shear Systems. Using our unique history as a provider of performance chemicals, Elgin has developed a line of drilling fluid jet shear systems. Jet shear systems are designed to use hydraulic shear to efficiently mix solids with liquids. Elgin’s jet shear systems ensure efficient mixing of soluble polymers and bentonite used in water-based drilling fluids, therefore, eliminating “fish eyes.” Drilling fluid yield and gel strength properties are instantly obtained with hydraulic shearing of bentonite or organophilic clays. Elgin provides several corrosion-resistant valve, hopper, and plumbing options. All units are fitted with pressure gauges and high-pressure ball valves for chemical injection. The hopper incorporates a bentonite loading bench and butterfly valve to enhance ergonomic addition of dry product.

We offer Tango 100hd2 Packaged Mud Recycling System. The Tango 100HD2 mud recycling and mixing unit was designed to provide an economical alternative to traditional mud mixing and vacuum trucks. Environmental pressures, dumping costs and down time while waiting on fresh water or vacuum truck turnaround, have made the Tango 100HD2 an invaluable asset. Fluid from the pit is pumped with a trash pump directly to the bottom deck of the double deck shaker. The solids are discarded off the rear and the fluid goes into the first compartment of the tank. The desilter pump pumps the fluid from the tank to the two 4” hydrocyclones. The desilter underflow goes over the top deck of the shaker where the solids are discarded off the rear and fluid is collected in first compartment of the tank. The clean fluid (overflow) goes into the second compartment of the tank. The transfer pump pumps the fluid from the second compartment to the rig pump. All pumps and the shaker have manual start and stop buttons on the control panel. The mud gun operates from the desilter pump. The Tango 100HD2 comes standard with a 500 gallon (1, 880 liters) tank and allows rig operators to prepare up to 500 gallons of mud.

We offer Mobile Centrifuge Systems. Mobile Ultra-Fine Solids Management With over 25 years of experience in the designing and manufacturing of reliable solids control equipment, Elgin understands the need for mobile ultra-fine solids management. The key to an effective solids control system starts with the control of fines. Uncontrollable fines increase equipment wear, lower the drilling rate of penetration, and can significantly hamper the rig’s pushpull capabilities. ESS-1448 HD2 XP Polisher System Features: Provides full integration with existing solids control assets. Utilizes a 30K triple-axel trailer. On board power and chemical injection available. Solids are discharged directly to an on-board screw conveyor for waste management. On-board PC pump feeds the centrifuge; Includes a self-priming centrate pump. Optional hydration manifold allows for thorough mixing of polymers.
