K. D. Dowls & Keys

Sanjay Colony, Faridabad, Haryana

• Min. Order (MOQ) 1 Piece
• Power Supply 85 to 265v AC, 50Hz
• Drive (i) For Cutting Stepper Motor (120 Kg Cm)
• (ii) Pulling steer motor (46kg cm)
• Dimensions 473mmx365x342mm
• Weight 62.5KG

• Min. Order (MOQ) 1 Piece(s)

Additional Information:

• Min. Order (MOQ) 1 Piece
• Weight 35kg
• Power 50Hz
• Length selection 5mm to 10000mm in meters in steps of 1mm(Smaller length option available)
• Accuracy +/-1mm OR +/-0.1 % depending upon wire length
• Ending Stripping 2mm to 25mm
• Wire cross section 0.5 to 3 sq. mm
• Wire type PVC
• Max wire programs 1 to 999 programs
• Changeover setting Tim 3 mins max for blade setting (Digital setting in 5 sec.)
• Wire feeding 2 wire 0.5 mm to 3 mm OD single wire 3.0mm
• Window cut It cut 7 window cut in one time
• Machenical system Small machine with non-maintenance, precision mechanical system
• Electronic system Micro processor controller
• Wire feed system 3 stepper motor with variable
• Cutting & stripping system V blade pair with stepper motor, variable speed with micro controller controlled
• Size of the main machine 360mmx200mmx280mm

• Min. Order (MOQ) 1 Piece
• Weight 40KG
• Power 1Ph
• Length 5mm to 10000mm in meters in steps of 1mm
• Accuracy +/-2mm OR +/-0.2 % depending upon wire length
• Wire cross section 0.5 to 4 sq. mm (multi core cable up to 3 core X 1sq.mm)
• Wire type PVC, Teflon, Glass wire
• Max. Wire programs 1 to 999 programs
• Changeover setting time 2 mm. Max for blade setting (digital setting in 5 sec)
• Wire Feeding 0.5mm to 3mm OD two wire one time processing
• Window cut It cut 7 window cut in one time
• Machine system Small machine with non-maintenance, precision mechanical system
• Electronic system Micro processor controller
• Wire feed system 3 stepper motor with variable
• Cutting & stripping system V blade pair with stepper motor, variable speed with micro controller controlled
• Length measurement system Directly by servo motor control
• Size of the main machine 420mmx200mmx45mm

• Min. Order (MOQ) 1 Piece
• Length selection 5mm to 10000mm in steps
• Accuracy depending upon wire length +/-2mm or +/-0.2%
• End stripping 2mm to 45mm
• Wire cross section 0.5 to 3mm od
• Wire type PVC, Teflon, wire
• Max. Wire Programs 1 to 999 program
• Window cut It cuts 7 window cut it one time

• Min. Order (MOQ) 1 Piece
• Weight 40 To 45kg
• Power 1Ph
• Length selection 5mm to 10000mm in meters in steps of 1mm
• Accuracy +/-2mm OR +/-0.2% depending upon wire length
• Wire cross section 0.5 to 4 sq. mm (Multi core cable up to 3core X 1sq.mm)
• Wire Type Pvc, Teflon, Glass Wire
• Max. Wire programs 1 to 999 programs
• Changeover setting time 2 min. Max for blade setting (Digital setting in 5 sec.)
• Wire feeding 0.5 mm to 3mm OD two wire one time processing & 3.5mm to 6mm OD single wire one time processing.
• Window Cut It cut 7 windows cut in one time.
• Mechanical system Small machine with non-maintenance, precision mechanical system
• Electronic system Micro processor controller
• Wire feed system 5 stepper motor with variable
• Cutting & stripping system V blade pair with stepper motor, variable speed with microcontroller controlled
• Length measurement system Directly by servo motor control
• Size of the main machine 420mmx200mmx450mm
