1 Products availableFeatures
Stainless Steel body of AISI 304 grade
Toughened glass window
Drums in acrylic and also in stainless steel (optional)
Automatic temperature control
Timer for total process time
Variable speed control
Air circulating fan and Flourescent Tube light
Feed Funnel for each Drum
Motor AC/DC geared of 0.37 kw / 0.18 kw 220 volts 50Hz
Heater Finned type for air heating of 2.0 kw / 1.5 kw
Machine size 1600 mm L * 450 / 350 mm B * 450 / 350 mm H
Packing size 1800 mm L * 700 mm B * 700 mm H
Gross WT :200 / 150 kgs approx.
We supply the PFI leather colour matching machine with 2, 4 or 6 drums as required.The drums are fabricated out of SS 316L grade stainless steel, driven commonly to the variable speed drive motor the temperature is common to all drums with electrical air heating having automatic temperature.Motor can be control with a timer and alarm for regular intervals.
Drum can be rotate clockas well as anti-clock wise with a manual rotary.Loading of leather is through the door which can be open and closed easily and draining is possible with the perforated section in a carefully designed sliding door.This machine is designed beautifully to carry out comparitive trails on all WET end chemicals like RETANNING, DYEINGAND FAT LIQUORING.The process can be viewed from the plexiglass on the drum also feeding of chemical can be done from the feed funnel without stopping the drum.
The PFI is the state of the art in your laboratory.
Model | R2 | R3 | R4 |
DRUM DIAMETER mm | 300 | 300 | 300 |
DRUM WIDTH mm | 150 | 150 | 150 |
DRUM VOLUME ltr. | 10 | 10 | 10 |
CAP.SHAVED WT. kg | 1x2 | 1x4 | 1x6 |
DRUM SPEED rpm | 4-40 | 4-40 | 4-40 |
MOTOR POWER kw | 0.37 | 0.55 | 0.75 |
HEATING POWER kw | 1 | 2 | 3 |
LENGTH mm | 1400 | 2300 | 3200 |
DEPTH mm | 650 | 650 | 650 |
HEIGHT mm | 500 | 500 | 500 |
WEIGHT kg | 260 | 340 | 420 |
FEATURES : This experimental drum is different from our other model which is having indirect electrical water/oil heating system allows to test with or without float always temperature control . The drum is manufactured in stainless steel 316, with glass shield on one side for process viewing .The sliding door with perforated section makes the loading and washing very easy.This drum is driven by
SEW EURODRIVE GERMANY GEARED MOTOR WITH SEW SPEED INVERTER CONTROL.
The heater is immersed in a tank with GRUNDFOS pump for circulation of water/oil in the double jacketed drum.The drum can work upto 60/100 degrees centigrate with clock anti-clock rotation with time control.
This drum washing machine can also be used for TEXTILE APPLICATION.
CE cerification is possible for the machine.
MODEL | 4020 I | 6030 I | 8035 I | 1040 I | 1050 I | 1250 I | 1260 I | 1450 I | 1460 I |
DIAMETER (mm) |
400 | 600 | 800 | 1000 | 1000 | 1200 | 1200 | 1400 | 1400 |
WIDTH (mm) |
200 | 300 | 350 | 400 | 500 | 500 | 600 | 500 | 600 |
CAPACITY (litre) |
25 | 85 | 150 | 315 | 390 | 565 | 680 | 769 | 920 |
SHAVED WEIGHT (kg) |
2 | 7 | 12 | 25 | 32 | 45 | 54 | 62 | 74 |
DRUM SPEED (Rpm) |
5/50 | 8/40 | 8/40 | 7/35 | 6/30 | 6/30 | 6/30 | 5/25 | 5/25 |
MOTOR POWER (kW) |
0.1 | 0.55 | 0.75 | 1.1 | 1.1 | 1.5 | 1.5 | 2.2 | 2.2 |
HEATING (kW) |
1 | 3 | 3 | 4.5 | 4.5 | 4.5 | 4.5 | 6 | 6 |
FEATURES :
Machine completely assembled ready for connection bodyparts made of SS 304 and drum of SS316L PERSPEX Glass to observe process with JK Colors "Z" TYPE circulating system to built in heater in box which is fixed to the axial of the drum. Hopper to add water, chemicals and bottom Drain value .Continous auto timer and other for manual operation automatic temperature. Sliding door, Variable stepless speed drive from SEW Germany Suitable to work at any process. All electrical Control panel are as per "CE"MARK fittings.
Features
Stainless Steel drum AISI 316 L grade
Plexiglass to observe process
Seperate heating pot to add chemical during process
Float circulation in Heating Pot where pH can be checked
Heater ON only Clockwise direction
Manually controlled Clock and Anticlock rotation
Automatic Temperature control
Timer for total process time with alarm
Variable speed control with SEW Eurodrive of Germany
MODEL | DRUM DIAMETER | DRUM WIDTH | DRUM VOLUME IN EACH DRUM | CAPACITY SHAVED WT | MOTOR POWER | HEATING POWER IN EACH DRUM | |
MIN | MAX | ||||||
6030
8035 1040 1050 |
600 mm
800 mm 1000 mm 1000 mm |
300 mm
350 mm 400 mm 500 mm |
85 ltrs
176 ltrs 315 ltrs 390 ltrs |
1 kg
5 kg 8 kg 10 kg |
6kg
16 kg 32 kg 40 kg |
0.37 kw
0.75 kw 1.1 kw 1.1 kw |
1.5 kw
3.0 kw 4.5kw 4.5 kw |
Palmarosa oil is extracted from cymbopogon martini (a.k.a. Cymbopogon martinii var. martinii) from the Gramineae family and also known as East Indian and Turkish geranium as well as Indian Rosha and Motia.
Chemical ConstituentsThe main chemical components of Palmarosa oil are: Geraniol, Citronellol, Farnesol, Citral, Citronellal, Geranyl Acetate, Dipentene and Limonene.
Application & Usage
Lemongrass essential oil is extracted from Cymbopogon flexuous (a.k.a. Andropogon flexuous, Andropogon flexuosus, Cymbopogon flexuosus - East Indian, Cochin, British India or native lemongrass) from the Poaceae family.
Chemical ConstituentsThe main chemical components of Lemongrass oil are: Citral, Farnesol, Nerol, Citronellal and Myrcene. Andropogon flexuosus and Cymbopogon flexuous has far higher Citral content than that of cymbopogon citrates.
Application & Usage
Nature & FeaturesAloe Vera is a succulent that belongs to the liliaceae family. It is one of the 250 known species of aloes, referred to by the scientific terms of Aloe Vera and Aloe Barbadensis called Ghrita Kumari in Sanskrit, it is commonly known as Aloe, Aloe Vera, Barbados Aloe, Sabila and Pita Sabila. Akin to cactus in appearance, it grows naturally in Africa, America, Europe and Asia.
Aloe Vera Products
Chemical Composition
Aloe vera leaf contains more than 200 different constituents. The juice contains, on average, more than 99% water. Major constituents are: Acemannan and other polysaccharides boost T-lymphocyte cells, which help promote skin healing and neutralize many of the enzymes responsible for damaging the mucosal wall Aloe-emodin, Aloins, Barbaloin and Isobarbaloin, amino acids the human body stops manufacturing its own mucopolysaccharides around puberty and from then on must rely on outside sources.
Application & Usage
Externally Aloe vera gel is helpful for
By Placing A Protective Coating On The Affected Areas Which
There are two types of itronella oil. Oil derived from Cymbopogon interianus is known as 'Java type' and that from Cymbopogon nardus as'Ceylon' type. Both are used to make cheap, 'lemony' perfumes for such things as toilet soap, household cleaners and aerosols designed to mask unpleasant smells. The Java-type oil is much richer in two chemical isolates - geraniol and citronella. Both these chemicals have a different use in the perfumery industry as part of more expensive and delicate perfumes, especially lily of the valley fragrances.
Citronella Oil JavaCitronella Oil Java type is the volatile oil obtained by Hydrodistillation of Cymbopogon winteranius Jowitt. The therapeutic properties of Citronella oil include antiseptic, deodorant, insecticide, parasitic, tonic and stimulant. Citronella oil's most useful quality is that of insect repellent.
Chemical CompositionGeraniol & Citronellal & various alcohol, and aldehydes. Citronella java type 85/35 oil contains a maximum of 85% Geraniol & Citronellal & various alcohol, and a minimum of 35% aldehydes, calculated as Citronellal
Application & Usage
