High Speed Numerically Controlled AC Servo driven Carbide Circular Saw Machines CNC Automatic and Semi Automatic versions to cut steel, non-ferrous Bars & sections from 10 mm to 300 mm. Features: Saw head Fully Automatic programmable with NC and Servo motor with Ball screw for saw feed to get optimum tool life. Good Surface finishes and faces squareness do not require facing operations. Achievable surface finish is around Ra 1.6. to 3.2. Can use Carbide Tipped and HSS Circular saws. Touch Screen. Job positioning manual with hydraulic clamping. Mechanical stopper for batch production.
| Keeping in pace with time and technology and meeting Customer's Expectations , ITL Industries Limited has yet come up with the State-of -the-Art High Speed Circular Sawing Machine .These machines are extremely fast compared to the conventional Double Column Band Saw Machine and are designed to cut ferrous and non ferrous metals like Mild Steel , Alloy Steels Copper , Bronze, Alluminium etc .These are production machines used for cutting channels , solid bars , hollows , flats, squares , angles and other sections of ferrous and non ferrous metal. It is a high productive , accurate and compact machine and has a high rate of production at comparatively low investment. With the thin TCT Cutter, it reduces parting losses and one gets very good surface finish . The machines are available in manual, semi-automatic , automatic and numerically controlled versions .These are available for cutting materials ranging from 10mm onwards up to 220 mm in four different models. |
<center><big>Specifications</center></big>
| Model | O.D. Range (mm) | Max. Tube Thickness (mm) | Speed in Mtrs./ min. Single | Speed in Mtrs./ min. Two | Speed in Mtrs./ min. Variable |
|---|---|---|---|---|---|
| TSM - 05 | 6 - 25 | 2 | 60 | 45 - 90 | 6 - 90 |
| TSM - 10 | 7 - 45 | 3 | 60 | 45 - 90 | 6 - 90 |
| TSM - 20 | 10 - 60 | 4 | 70 | 6 - 120 | 6 - 120 |
| TSM - 30 | 16 - 90 | 5 | 75 | 6 - 120 | 6 - 120 |
| TSM - 40 | 20 - 115 | 6 | 50 | 50 - 100 | 10 - 100 |
| TSM - 50 | 25 - 140 | 6 | 40 | 30 - 60 | 6 - 60 |
| TSM - 60 | 50 - 169 | 7 | 30 | 15 - 30 | 5 - 50 |
| TSM - 80 | 90 - 219 | 8 | 30 | 15 - 30 | 3 - 30 |
| Note : Ten Rolls Tube Straightening Machines are also available. | |||||
<center><big>Specifications</big></center>
| Description | TPM - 1 | TPM - 2 | TPM - 3 | TPM - 4 | TPM - 5 |
|---|---|---|---|---|---|
| Tube dia range | 10 - 50 mm | 20 - 76 mm | 30 - 115 mm | 50 - 170 mm | 90 - 220 mm |
| Max wall thickness | 4 mm | 6 mm | 8 mm | 10 mm | 15 mm |
| Min. to OD thickness ration | 10 mm | 10 mm | 10 mm | 10 mm | 15 mm |
| Pointing time | 30 sec. | 30 sec. | 40 sec. | 50 sec. | 60 sec. |
| Max. pointing length | 160 mm | 160 mm | 250 mm | 300 mm | 300 mm |
| Power Rating | 7.5 H.P | 10 H.P | 12.5 H.P | 15 H.P | 20 H.P |
| Max. working pressure | 200 | 200 | 200 | 200 | 200 |
| Max. load capacity | 60 T | 100 T | 140 T | 190 T | 250 T |
| Machine floor size | 1500 x 200 mm | 1800 x 2200 mm | 1900 x 2300 mm | 2000 x 2500 mm | 220 x 2800 mm |
| Weight (approx.) | 1500 | 2100 | 2800 | 3600 | 4500 |
<center><big>Specifications</big></center>
| Sr. No. | Pipe Nominal Bore | Spindle R.P.M. App. | Power Required (HP) | Power Required (R.P.M.) |
|---|---|---|---|---|
| 1. | 1/2" to 1-1/2" | 90 & 120 | 3 | 1000 |
| 2. | 1/2" to 2-1/2" | 60, 90 & 120 | 7.5 | 1500 |
| 3. | 1" to 4" | 40, 75 & 115 | 10 | 1000 |
| 4. | 2-1/2" to 6" | 25 & 50 | 15 | 1000 |
| ||||||||||||||
