Logic Analyzer in Indore

• Printer : Print all data on screen to printer
• Memory Capacity : 1k data/every channel.
• Setup Time : 4 μsec in internal mode 0 μsec in external mode
• Supply Type : Manufacturer
• Threshold Voltage : TTL (1.4V).
• No. of Channels : 48
• Trigger Setup Time : More than 20 μsec.
• Repeater on Trigger : Automatically starts a new data acquisition cycle after the completion of last cycle and upon detection of trigger word.
• Trigger Position : 128 to 1920 data before trigger and 1920 to 128 data
• Input Impedance : 1 M Ohm. input capacitor

more...

• Sampling frequency : 125MHz
• Data dynamic record : support
• Trigger : level trigger, edge trigger, external trigger
• Synchronous sampling rate : 125M(external CLK cable)
• Supply Type : Manufacturer
• Realtime display sampling frequency : 125Mhz(Max)
• Input signal range : 0~5V
• System : Windows 2000, Windows XP, Windows 7(32&64)
• USB version : USB2.0 high speed
• CH memory depth : 512Kbits

Features: sampling cycle could set as 8ns, 10ns, 20ns, 50ns, 100ns,  200ns, 500ns, 1us…100ms, it also means from 125MHZ,  100MHZ to 10HZ Support 125M external synchronous time Adopts high compression algorithm, compression rate will auto adjust from 1:1 to 1^37:1. If 125M sampling, 1024S has 36Bit memor more...

• External clock : 8 channels 0-80MHz
• Trigger level : 16 levels 80 channels complex
• Pattern Generator : 0 ~ 50MHz (0 ~ 100MHz rate (Optional)
• Threshold voltage : 6 sets 6.4V ~ +6.4V
• Memory : 512K/48 channels 256K/80 channels
• Trigger quality : 8 channels
• Supply Type : Manufacturer
• Frequency : 500Mhz 48 channels 1Hz ~ 250MHz 16 channels
• Input impedance : 200KW/5pF
• Power supply : DC Adapter 5V/10A

FEATURES High speed operation (up to 500M samples per second) Up to 80 data input channels Deep data buffers (up to 512K samples per channel) Continuously variable pre/post trigger position 200KW/ more...

Capture and display multiple signals from a digital system or digital circuit. Cursors are provided to analyze signal and result can be stored in Image format. more...

Product Description Memory Memory : 512Kbits Depth(Per Channel) : 32Kbits (Max 8Mbits for compression) Trigger Condition : PatternEdge Trigger Channel : 16 CH Post Trigger : YES Trigger Level : 1 Level Trigger Count : 1~65535 more...

Sophisticated Trigger Captures the Data you want The LA-4000 & LA-5000 captures the data that is important for your logic analysis. Sophisticated 16 level triggering allows fine tuning of the exact point to start data captures. The continuously variable prepost trigger allows the trigger to be placed anywhere more...
