CONTROL MODULES : Leakage free control module having +/-2.0% FSD accuracy, ranging from 0-100LPM for PM and 0-10LPM for inorganic gases pollutant with logging of corrected totalize volume of individual parameter PM+GAS
GASEOUS SAMPLING: : 0 - 10 LPM collection in a set of borosilicate glass impingers.
Feature : Accuracy, Easy To Fit, Perfect Strength, Robust Construction
Type : Stack Monitoring Kit, STACK MONITORING SYSTEM
PC COMMUNICATI ON AND DATA : Barometric Pressure or Altitude. Pitot tube co-efficient. Stack or Duct dimensions. Molecular weight or composition of stack gas. Condensate Water. Initial & Final weight of filter thimble
Monitoring of stacks and vents are requirement to ensure that emission of air pollutants are within the limit prescribed by regulatory authorities. By regular monitoring of emission one can establish that functioning and performance of installed control system are within the desimore...
Filter Holder : Fabricated from SS 304 tube suitable to hold either cellulose filteration thimble (size 28 mm ID x 100 mm ling) or glass micro fibre thimble (size 19 mm ID x 90 mm long).
Stack Gas Temp. : Up to 600 degree C A digital pyrometer and 1m
Long thermocouple is provided
Vacuum Pump : Monoblock Rotary vane type oil less, 0.5 HP, Single phase moter (230 V) with 40lmp free flow capacity.
Sampling Probe : Made from SS 304 tube, 1.0m length extendable to 2.0m
Digital Clock : 0-60 minutes, 1 second readout with start stop and reset functions.
Rotameter : Plastic body rotameter with 2% FSD accuracy, 0-30 lpm for particulate and 0-3 lpm for gases.
Stack Monitoring Kit Consisting as follows: 1) Temperature Range Ambient to 600°C 2) Set of Inter Connection Hoses Pipes. 3) Double Wall Cold Ice Box. 4) Rotary Van type Vacuum pump Cap. 100 LPM. 5) Dry Gas Meter Assembly. 6) Velocity measuring Kit 7) Pitot Tube. 1-meter length.more...
We are offering stack monitoring kit. It is used for rapid and accurate measurements of concentrate gaseous pollutants such as so2, nox and also suspended particulate matter (spm) under isokinetic conditions, volumetric flow, linear velocity and stack gas temperature. It meets wimore...
Compact Yash stack monitoring kit for the monitoring of particulate matter, so2, NOx in the flue gas. Yash stack kit consists of control module, velocity kit, vacuum pump, impinger box, pitot tube, thimble holder, k-type thermocouple, connecting hose etc. more...
stack monitoring kit is designed to measure Temperature, Differential pressure and Static pressure for determination of velocity, volumetric flow and Particulate sampling under Isokinetic conditions. Monitoring of gaseous pollutants such as: Sulphur Dioxide (SO2), Sulphur Trioxidmore...
Stack Monitoring kit can be used to measure total emission of particulate matter and gaseous pollutants from the stacks of almost all types of industries including Thermal Power Stations, Steel Plants, Chemical Plants and Cement Industry. In its simplest form, it can be used to tmore...
Stack Monitoring Kit Consisting as follows: 1) Temperature Range Ambient to 600°C 2) Set of Inter Connection Hoses Pipes. 3) Double Wall Cold Ice Box. 4) Rotary Van type Vacuum pump Cap. 100 LPM. 5) Dry Gas Meter Assembly. 6) Velocity measuring Kit 7) Pitot Tube. 1-meter lengtmore...
stack temperature range : ambient to 600 deg c read on a digital pyrometer stack velocity range : 3 to 60 m/sec thermocouple : t/c sensor in ss 304 casing, length of insertion : 0.6m with 2 m long cable manometer : digital with 0 -1200 mm of h20 range pilot tube : calibrated s-tymore...
Specifications : Stack Temperature Range: Ambient to 600 deg C read on a Digital Pyrometer. Stack Velocity Range: 3 to 60 m/sec Thermocouple: T/C sensor in SS 304 casing, length of insertion: 1 m with 2m long cable.
MAIN FEATURES Specially to monitor Dioxins, Furan & provision for monitoring of Heavy Metals emissions Collection based on wet chemical techniques Measures total quantity volume of the emissions Heating Probe & box assembly with auto temp controller Rugged & convenient for samplimore...
FEATURES : Cumbersome Manometer has been replaced with digital pressure cell Designed to determine the velocity of gases also. Measures total quantity/volume of the emissions very accurately. Size and weight of panel has been reduced considerably. Etc
Specifications : Stack Temperature Range: Ambient to 600 deg C and 500-1000C read on separate Digital Pyrometers Etc
The most common and widely used method (world over) is extractive sample method or Grab sampling technique. Grab sampling technique is also often treated as the reference standard method. Grab Sampling technique is not restricted to a specific pollutant. The same system with diffmore...
FEATURES : DigitalPressure Cell in place of cumbersome manometer. Measures total quantity I volume of emissions. Determines velocity of gases. Reduction in size and weight of panel. Extendable arm for pitot and probe pipe. Etc.
The most common and widely used method (world over) is extractive sample method or Grab sampling technique. Grab sampling technique is also often treated as the reference standard method. Grab Sampling technique is not restricted to a specific pollutant. The same system with diffmore...
Located in Delhi, India, we are actively functioning as Manufacturer, Supplier ad Exporter of Stack Sampler all over the country and overseas. Our complete environmental solution Stack Sampler is developed by our team of experts in order to provide a sturdy, simple, reliable and more...
