HDPE Rollers for Belt Conveyor

Using the on-site extrusion machinery, SKE Industries ensures the non-toxic and recycled HDPE pipes of superior quality, which have higher tensile strength and impact resistance properties.

APPLICATION

HDPE conveyor rollers are generally used in the dusty and corrosive environment such as mining industry, iron and steel, cement, smelting, power, chemistry, construction material, coal washing, foodstuff processing, port activities etc.

FEATURES

1. Non-corrosive excellent abrasion resistance.

2. 50% Lighter than steel roller, long lifespan.

3. Lower start-up costs on conveyer drives.

4. Recyclable, energy efficient, decreases vibration.

5. Lowers maintenance costs, minimizes damage to conveyer belts.

6. Non-toxic HDPE pipe.

7. Water-tight sealing arrangement.

8. Performs well in harsh weather and extreme applications.

HDPE Roller Spec.

Roller Dia. (mm) 89, 108, 133, 102, 127

HDPE Tube Thickness (mm) 9.0, 9.5, 10.5, 11.0

Inner Steel Tube Dia. (mm) 65, 80, 108, 102

Inner Steel Tube Thickness. (mm) 1.5, 2.0

Roller Shaft Dia. (mm) 20, 25

Roller Length (mm) 186 - 1632 *

Belt Width (mm) 300 - 1400

Bearings No. 6204, 6205

Standard DIN, CEMA, JIS, AS, etc.

Return Rollers for Belt Conveyor

We are conveyor return roller manufacturer and provide flat return roller, self-aligning return roller, v return roller, and friction return roller for sale. You can contact us for quotation now.

APPLICATION

Belt conveyor return rollers are used to support the belt as it cycles around to be loaded again. Standard Return Rollers are available with a steel roll and 2 drop brackets. Return roller support the belt to prevent stretching, sagging, and failure.

Specification of Conveyor Return Rollers

Type Belt Width (mm)

Flat Return Roller (1 roller) 300 - 2000

V Return Roller (2 rollers) 650 - 2200

Self-aling Carry Roller (1 rollers) 400 - 1600

Self-aling Carry Roller (2 rollers) 400 - 2200

Standard DIN, CEMA, JIS, AS, SANS-SABS, GOST, AFNOR etc.

Specifications of Heavy Duty Steel Conveyor Rollers

Roller Dia. (mm) 63, 89, 108, 133, 159, 194, 219

No-standard Roller Dia. 76, 102, 114, 127, 140, 152 , 168, 178

Roller Shell Thickness (mm) 3, 3.5, 4, 4.5, 5.0, 6.0, 6.3

Roller Shaft Dia. (mm) 15, 20, 25, 30, 40

Roller Length (mm) 186 - 3382

Belt Width (mm) 300 - 3000

Bearings 6204, 6205, 6305, 6206, 6306, 6308

Material Steel

Standard DIN, CEMA, JIS, AS, SANS-SABS, GOST, AFNOR etc.
