Our Products
Leading Manufacturer, Supplier & Retailer of MIG Welding Machine, radial drill press, Heavy Duty Center Lathe, All Geared Head Vertical Milling Machine and Universal All Geared Head Milling Machine.
Unique design manually operated which is developed for low cost production without electricity. Square and Round Pipes, Metal and Stainless Steel Products, Flat Angle Channel Bar. Dies are also available as per customer specification. Specially for stairs contrail pipe bending.
HPSM’ Milling Drilling Machines offered by us are greatly demanded by the clients due to the high quality and excellent working. The Milling Drilling Machine is manufactured using the latest technology and the finest components & parts. The Milling Drilling Machine is suitable for varied drilling requirements at varied industries.
HPSM’ offer Plano miller machines that are dimensionally accurate and have functionally superior operational standards. We manufacture these Plano miller machines under the close surveillance of expert professionals to ensure delivery of zero defect products to our clients. These machines are resistant to corrosion & abrasion and perfectly meet the application demands of different industries.
Standard Accessories
Extra or Optional Accessories
| Technical Specifications | ||||||||
| Stroke | Width | Height | ||||||
| 2500 | 1200 | 1000 | ||||||
| 3000 | 1200 | 1000 | ||||||
| 3000 | 1500 | 1200 | ||||||
| 3600 | 1500 | 1200 | ||||||
| 4000 | 1500 | 1200 | ||||||
| 4000 | 2000 | 1500 | ||||||
| 5000 | 1500 | 1200 | ||||||
| 5000 | 2000 | 1500 | ||||||
| 6000 | 1500 | 1200 | ||||||
| 6000 | 2000 | 1500 | ||||||
| 8000 | 1500 | 1200 | ||||||
| 8000 | 2000 | 1500 | ||||||
| 8000 | 2500 | 2000 | ||||||
| 8000 | 3000 | 2500 | ||||||
| 8000 | 3600 | 2500 | ||||||
| 10000 | 1500 | 1200 | ||||||
| 10000 | 2000 | 1500 | ||||||
| 10000 | 2500 | 2000 | ||||||
| 10000 | 3000 | 2500 | ||||||
| 10000 | 3600 | 2500 | ||||||
| 10000 | 3600 | 3000 | ||||||
With advanced manufacturing techniques, we manufacture, supply and export Valve Refacer Machine. These machines are fabricated by making use of robust material and latest production methods. Valve Refacer is offered in varied technical specifications to meet the requirements of our large clientele.
Features
HPSM Mechanical Center less grinder is able to faster grinding with better surface finishes, than competing machines. We manufacture, supply and export Mechanical Center less Grinder at best price with high reliability, easy operation, and low maintenance. These grinding machines are an ideal asset to every industry.
Salient Features
Optional Accessories
Standard Accessories
| Technical Specifications | ||||||||
| Particulars | HPS 100 | HPS 150 | HPS 200 | |||||
| Grinding Capacity in mm | 1 to 75 | 1 to 75 | 1 to 75 | |||||
| Grinding Wheel Size | 350 x 700 x 127 | 350 x 700 x 127 | 350 x 700 x 127 | |||||
| Grinding Wheel Speed : R.P.M | 1800 / 2000 | 1800 / 2000 | 1800 / 2000 | |||||
| Regulating Wheel Size | 225 x 100 x 76.2 | 225 x 100 x 76.2 | 225 x 100 x 76.2 | |||||
| Regulating Wheel Speed | 15 x 45 x 100 | 15 x 45 x 100 | 15 x 45 x 100 | |||||
| Power | ||||||||
| Grinding Wheel Motor | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) | |||||
| Regulating Wheel Motor | 1 H.P. | 1 H.P. | 1 H.P. | |||||
| Hydraulic Unit Motor | 1 H.P. | 1 H.P. | 1 H.P. | |||||
| Coolent Pump Motor | 0.10 HP | 0.10 HP | 0.10 HP | |||||
| Power Supply | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 | |||||
HP Singh Machinery Pvt. Ltd is one of the leading expertises in manufacturing and exporting Hydraulic Center less Grinding Machines. We provide these machines in the market at very economical price. Our Center less Grinding Machines is innovative design, high rigidity, high accuracy, high efficiency, guaranteed quality.Salient Features
Optional Accessories
Standard Accessories
| Particulars | HPS 100 | HPS 150 | HPS 200 |
| Grinding Capacity in mm | 1 to 75 | 1 to 75 | 1 to 75 |
| Grinding Wheel Size | 350 x 700 x 127 | 350 x 700 x 127 | 350 x 700 x 127 |
| Grinding Wheel Speed : R.P.M | 1800 / 2000 | 1800 / 2000 | 1800 / 2000 |
| Regulating Wheel Size | 225 x 100 x 76.2 | 225 x 100 x 76.2 | 225 x 100 x 76.2 |
| Regulating Wheel Speed | 15 x 45 x 100 | 15 x 45 x 100 | 15 x 45 x 100 |
| Power | |||
| Grinding Wheel Motor | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) |
| Regulating Wheel Motor | 1 H.P. | 1 H.P. | 1 H.P. |
| Hydraulic Unit Motor | 1 H.P. | 1 H.P. | 1 H.P. |
| Coolent Pump Motor | 0.10 HP | 0.10 HP | 0.10 HP |
| Power Supply | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 |
HPSM Hydraulic Cylindrical Grinding Machine ideally suited to performing repetitive grinding operations or small quantity production with equal ease. It can grind both Rubber and Steel by only changing the Grinding Plate. Features of our existing range of machines.
| Technical Specifications | |||||||
| Centre distance | 300mm | 450mm | 600mm | 1000mm | 1250/1500mm | 2000mm | 2500mm |
| Centre height | 125 | 150 | 150 | 175mm | 200mm | 200mm | 200mm |
| Work piece max. weight | 30 | 50 | 70 | 80 | 100 kg | 500 kg | 700 kg |
| Swing over table | 250 | 300 | 300 | 375 | 400mm | 400mm | 400mm |
| Grinding Wheel diameter, width and bore | 350X38X 125 |
400x38x 125 |
400x38x 125 |
450x63x250 | 500x50x250mm | 450x63x250mm | 450x63x250mm |
| Power requirement in wheel head | 2.2 | 3.7 | 3.7 | 3.7 | 5.5kw | 5.5kw(7.5HP) | 5.5KW(7.5HP) |
| Power requirement in work head | 0.74 |
0.74 |
0.74 |
0.74 | 1.5 KW | 1 HP | 1 HP |
| Fitting taper | MT 3 | MT 3 | MT 3 | MT 4 | MT 4 | MT-4 | MT-4 |
| Travel of barrel | 30 | 35 | 35mm | 40 | 40mm | 40mm | 40mm |
| Fitting taper in tailstock | MT 3 | MT 3 | MT 3 | MT 4 | MT 4 | MT-4 | MT-4 |
| Max. swivel of table, degree | 5 | 5 | 5deg | 5 | 5 | ||
HPSM Hydraulic Cylindrical Grinding Machine ideally suited to performing repetitive grinding operations or small quantity production with equal ease. It can grind both Rubber and Steel by only changing the Grinding Plate. Features of our existing range of machines.
From the market studies, we have developed Drilling Cum Tapping Machine. With the help of this Drilling Cum Tapping Machine you can do drilling and threading process simultaneously. We are providing automatic electric type tapping attachment with our machine. This attachment includes foot mounted switch so that you can do reverse forward action without the help of your hand. This attachment will come along with all type of Pillar drilling machines having range from 25 mm to 40 mm.
We are the leading suppliers of qualitative selection of Vertical Gear Head Milling Machine. Offered machine is perfectly manufactured using superior quality component and state of art technology by our skilled experts. Provided machine is widely acclaimed at various industries for its easy operations. This machine is properly checked by our quality experts to assure its quality.
| Model | Model No.2 | Model No.3 |
| Table | ||
| Length X Width | 1270X280mm | 1450 X 310mm |
| Number and Width of ‘T’ slots | 3-16mm | 3-16mm |
| Centre distance between T slots | 67mm | 78mm |
| Power operated Longitudinal traverse | 660mm | 735mm |
| Power operated cross traverse | 254mm | 310mm |
| Power operated vertical traverse | 400mm | 500mm |
| Swivel of table to either side | 45 deg | 45 deg |
| Vertical Spindle | ||
| Number of speeds | 9 | 9 |
| Speed range | 50 to 550 RPM | 50 to 550 RPM |
| Spindle Nose | ISO 40 | ISO 40 |
| Swivel of milling head to either side | 45 deg | 45 deg |
| Vertical quill movement | 90mm | 115mm |
| Feeds | ||
| Number of feeds | 9 | 9 |
| Feed range a) Longitudinal b)Cross c)Vertical |
10–187mm/min 9-161mm/min 1.3-24mm/min |
10 –187mm/min 9-161mm/min 1.3-24mm/min |
| Vertical Movement | ||
| Rapid rate 1. Longitudinal b) Cross c) Vertical |
1300mm/min 1100mm/min 165mm/min |
1300mm/min 1100mm/min 165mm/min |
| Power | ||
| Main Motor | 3 HP with 960 RPM | 3 HP with 960 RPM |
| Feed motor | 2 HP with 960RPM | 2 HP with 960RPM |
| Coolant pump | 0.10HP with 2850RPM | 0.10HP with 2850RPM |
HPSM is proudly serving the industry since years we are in offering a premium range of best quality machines like Universal All Geared Milling Machines. In fabrication of HPSM Milling Machines we used High Quality, close grained cast Iron. All Slides Grinds on Slide way Grinder and closely scraped.
Standard Accessories
Optional Accessories
| Technical Specifications | ||||||||
| Table: | No.2 | No.3 | No.4 | No.5 | ||||
| Working Surface | 1300 x 300 | 1400 x 330 | 1600 x 350 | 1800 x 400 | ||||
| T-Slot Nos/Size | 316 | 3.22 T NUT | 3.22 T NUT | 3.22 t nut | ||||
| T-Slot Centre | 70 | 80 | 85 | 90 | ||||
| Swivel | +/-45deg | +/- 45DEG | +/-45DEG | +/-45 deg | ||||
| Longitudinal Travel by power X | 700 | 800 | 1000 | 1200 | ||||
| Cross Travel by power Y | 215 | 260 | 340 | 380 | ||||
| Vertical Travel by power Z | 450 | 510 | 600 | 650 | ||||
| Feeds: | ||||||||
| No. of Feeds | 18 | 18 | 18 | 18 | ||||
| Range of Longitudinal Feed / Min | 23-420 | .23-420 | 23-420 | 23-420 | ||||
| Range of Cross Feed / Min | 23-420 | 23-420 | 23-420 | 23-420 | ||||
| Range of Vertical Feed / Min | 3-70 | 3-70 | 3-70 | 3-70 | ||||
| No. of Rapid Feeds | 1 | 1 | 1 | 1 | ||||
| Longitudinal Rapid Feeds / Min | 735, 1065 | 29,42 | 735, 1065 | 29,42 | ||||
| Rapid Long & Cross / Min | 1050 | 1050 | 1050 | 1050 | ||||
| Rapid Vertical / Min | 175 | 175 | 175 | 175 | ||||
| Spindle: | ||||||||
| No of Spindle Speeds | 12 | 12 | 12 | 12 | ||||
| Range of Spindle Speeds | 40 to 1200 rpm | 40 to 1200 rpm | 40 to 1200 rpm | 40 to 1200 rpm | ||||
| Spindle Taper | ISO-40 | ISO-40 | ISO-40 | ISO-40 | ||||
| Arbour Diameter | 25.4 | 25.4 | 32 | 40 | ||||
| Power: | ||||||||
| Main Motor | 3 HP | 5 HP | 7.5 HP | 10 HP | ||||
| Feed Motor | 2 HP | 2 HP | 3 HP | 3 HP | ||||
| Coolant Motor | 0.1 HP | 0.1 HP | 0.1 HP | 0.1 HP | ||||
HPSM is a renowned manufacturer, supplier and exporter of Flat Die & Thread Rolling Machines. We have been providing quality machines to our clients at the most reasonable prices. Using advanced techniques and skills of an experienced personnel, we produce a world class range of products so that it meets to our clients requirements.
| SPECIFICATION OF FLAT DIE THREAD ROLLING MACHINES | |||||||
| Type of Machines | A | B | C | D | E | F | G |
| Min.Max. Dia Can Be Rolled | 1/16″ 1/4″ | 1/8″-1/2″ | 1/8″-1/2″ | 1/4″-5/8″ | 1/4″-3/4″ | 1/4″-7/8″ | 3/8″-1″ |
| Maximum Length of thread | 2″ | 21/2″ | 3″ | 3″ | 4″ | 4″ | 4″ |
| Dimension of Fixed die | 3″X2″X1″ | 5″X21/2X1″ | 5″X3″X1″ | 6″X3″X1″ | 6″X4″X1″ | 7″X4″X1″ | 8″X4″X11/2″ |
| Dimension of moving die | 4″X2″X1″ | 6″X21/2″X1″ | 6″X3″X1″ | 7″X3″X1″ | 7″X4″X1″ | 8″X4″X1″ | 9″X4″X11/2″ |
| Production In Pieces per minute | 80 | 60 | 60 | 50 | 30 | 30 | 20 |
| Power required in H.P |
2 | 3 | 5 | 7.5 | 10 | 15 | 20 |
HPSM deals with latest technologies based 3 Roll Hydraulic Threading Machine that have been designed to make industrial tasks easier, faster and error free. Before it is dispatched, it is tested many times in our production house, which means that you dont need to worry about anything.
| Three Roll Type | HPS3R-25 | HPS3R-50 | HPS3R-75 | ||||
| Work Range | Out Side Diameter | 10-25 mm | 3/8″ – 1″ | 15-50 mm | 5/8″-2 | 25-75 mm | 1″-3″ |
| Thread Length in Feed | 38 mm | 1.1/2 | 50 mm | 2″ | 75 mm | 3″ | |
| Thread Length Through Feed | Indefinite | Indefinite | Indefinite | Indefinite | Indefinite | Indefinite | |
| Max. Thread Pitch | 0.7 – 2 mm | 32-12 TPI | 32-8 TPI | 32-8 TPI | 0.8-6 mm | 32-4 TPI | |
| Roll Dies | Max. Out Side Dia. | 80 | 140 | 160 | |||
| Max. in Side Dia. | 28 | 40 | 54 | ||||
| Max. Width | 38 | 50 | 80 | ||||
| Motor | For Roll Spindle | 2 H.P. | 5 H.P. | 10 H.P. | |||
| 3 Phase AC | For Hydraulic System | 2 H.P. | 3 H.P. | 5 H.P. | |||
| Coolant Pump | 0.1 H.P. | 0.1 H.P. | 0.1 H.P. | ||||
HPSM deals with latest technologies based 2 Roll Hydraulic Threading Machine that have been designed to make industrial tasks easier, faster and error free. This heavy duty machine is designed for rolling pressure upto 30 tons and provided with highly efficient gear box and removable in-built Hydraulic Power pack. Deflection is minimized by using large dia spindle mounted in especially accurate heavy duty bearings.
HPS-80A
Salient features
This machined is designed for rolling pressures upto 16 ton. The rigid spindle assembles permits precise & accurate rolling of work piece
Salient features
HPS-24B
The HPS-24B form & thread rolling machine is most compact form & thread rolling machine available in the market. Its unique design concept is primarily aimed at covering the widest universal range of applications. The rolling of threads, knurls, vross knurls, worms & spindles etc as means of tilting rolling spindle the longer working piece such as bars upto 6 mtrs long can be rolled by the through feed rolling method
Salient features
| Technical Specifications | |||
| HPS-80A | HPS-42D | HPS-24B | |
| Workpiece Ø (infeed) | 10-80mm | 3-50mm | 3-24mm |
| Max pitch of thread (Standard V Thread) | 10mm | 5mm | 3mm |
| Max serrations pitch | 3mm | 1.6mm | 1.0mm |
| Max. Die. Width | 200mm | 150mm | 80mm |
| Max.Through feed thread length | 6 meter | 6 meter | 6 meter |
| Max. Rolling Force (infinitely adjustable) | 30 tons | 16/20 tons | 8 tons |
| Spindle Axis swivel for through feed | 120 | 50 | 50 |
| Roll spindle Ø | 69.85mm | 54mm | 40mm |
| Max Rolling Die Ø | 220mm | 180mm | 120mm |
| Roll spindle speed (RPM) | 16/22/34/73/110/150 | 20/40/60 | 60/90 |
| Main Motor | 11 kW | 3.7 kW/5.6 kW | 2.2kW |
| Hydraulic powerpack motor | 2.2 kW | 1.5 / 2.2 kW | 0.75 kW |
| Coolant pump | 1/2 HP | 1/8 HP | 1/8 HP |
| Electrical connection | — 415 V, 50 Hz, 3 Phase — | — 415 V, 50 Hz, 3 Phase — | — 415 V, 50 Hz, 3 Phase — |
| Approx. Weight | 3500 Kg | 2200 Kg | 1000 Kg |
HPSM is one of the leading expertise in manufacturing and exporting various Slotting Machines. These slotting machines are used in varied industries for heavy duty operation like in the automotive, furniture, electrical, construction and heavy industry. Slotting Machine with Rotary Auto Feed makes the function more effective which increases its demand in market.
| Technical Specifications | ||||||||||||
| Model | HPS – 150 | HPS – 250 | HPS – 300 | HPS – 450 | ||||||||
| MM | INCH | MM | INCH | MM | INCH | MM | INCH | |||||
| Length of Stroke Maximum | 175 | 6 ¾ | 250 | 9 ¾ | 325 | 12 ¾ | 475 | 18 ¾ | ||||
| Working Stroke | 150 | 6 | 250 | 9 ¾ | 300 | 11 ¾ | 450 | 17 ¾ | ||||
| Ram Adjustment | 125 | 5 | 200 | 8 | 250 | 9 ¾ | 325 | 12 ¾ | ||||
| Length of Ram Bearing | 500 | 19 ¾ | 550 | 21 ½ | 625 | 24 ½ | 875 | 34 ½ | ||||
| Throat Adjustment | 300 | 11 ¾ | 350 | 13 ¾ | 500 | 19 ¾ | 675 | 26 ½ | ||||
| Maximum Diameter accomodated when machine at centre | 500 | 19 ¾ | 750 | 29 ½ | 850 | 33 ½ | 1500 | 59 | ||||
| Height Between Table & Head | 300 | 11 ¾ | 375 | 14 ¾ | 450 | 17 ¾ | 700 | 27 ½ | ||||
| Longitudinal Feed (Manual) | 200 | 8 | 325 | 12 ¾ | 450 | 17 ¾ | 625 | 24 ½ | ||||
| Longitudinal Feed (Auto) | 175 | 6 ¾ | 300 | 11 ¾ | 425 | 16 ¾ | 575 | 22 ½ | ||||
| Cross Feed (Manual) | 225 | 8 ¾ | 250 | 9 ¾ | 400 | 15 ¾ | 550 | 21 ½ | ||||
| Cross Feed (Auto) | 200 | 8 | 225 | 8 ¾ | 375 | 14 ¾ | 500 | 19 ¾” | ||||
| Dimension of Table | 275 | 10 ¾ | 375 | 14 ¾ | 600 | 23 ½ | 900 | 35 ½ | ||||
| Number and Ranges of Speeds | 2 (30-50) | 2 (30-50) | 3 (30-60-90) | 3 (30-60-90) | 3 (25-40-65) | 3 (25-40-65) | 6 (10-15-25-35-50-70) | 6 (10-15-25-35-50-70) | ||||
| Motor Recommended (960 RPM) | 1.5 HP | 1.5 HP | 2 HP | 2 HP | 3 HP | 3 HP | 5 HP | 5 HP | ||||
| Net Weight | 850 Kg. | 850 kg. | 1200 kg. | 1200 Kg. | 1750 kg. | 1750 kg. | 4000 kg. | 4000 kg. | ||||
| Gross Weight | 975 Kg. | 975 kg. | 1400 kg. | 1400 kg. | 1925 kg. | 1925 kg. | 4500 kg. | 4500 kg. | ||||
| Packing Dimensions | 1700 x 850 x 1200 | 1700 x 850 x 1200 | 2100 x 1400 x 900 | 2100 x 1400 x 900 | 2300 x 1500 x 1100 | 2300 x 1500 x 1100 | 2500 x 2200 x 1600 | 2500 x 2200 x 1600 | ||||
HPSM deals with latest technologies based cutting machines that have been designed to make industrial tasks easier, faster and error free. We are a renowned manufacturer, supplier and exporter of Hacksaw Machines which are appreciated for their smooth & swift functioning ability, high efficiency, fine cutting and long lasting trouble free service, durability, reasonable rates.
STANDARD ACCESSORIES
Introduction
Matchless Brand Hydraulic Control Hacksaw Machine has been designed to cut quickly & accurately all material from nickel chrome steel to plastic, controls are simple & easy. An automatic cut out operates at the completion of the operation & The bow slide returns to the top position, The machines has attractive appearance.
Saw Frame
Matchless Brand Hydraulic Control Hacksaw Machine has been designed to cut quickly & accurately all material from nickel chrome steel to plastic, controls are simple & easy. An automatic cut out operates at the completion of the operation & The bow slide returns to the top position, The machines has attractive appearance.
Speed
Two speeds has been provided in order to make it suitable for all metals. High speed for metals like mild steel, brass, copper etc and low speed for cast iron.
Vice
The vice is rigid construction. The one jaw remains fixed while other can be adjusted according to the size of the material to be cut.
Electricals
Push button starter is fitted with an adjustable trip mechansim which stops the machine soon after the blade is clear from work at extra cost.
Bed
The bed is of rigid casting with a wide through for collection of coolant, swarf & also houses the V-belts device, bed is single piece casting.
The Drive
The drive is given to the machine through V-Pullys with provision to adjust fully the tension of the V-Belts. The shafts are fitted with taper and ball bearings which eliminate friction.
Feed Saw
Feed saw is controlled hydraulically by two levers provided at the dash-pot. One controls the rate of feed, while the other enables the bow slide to be raised or lowered and the motor gets switched off on completion of the cut.
Coolant
The coolant tank is totally enclosed in the machine base with a constant speed pump which continuously supplies coolant to the saw blade.
| Technical Specifications | ||||||||||
| Model | HPS-175 | HPS-200 | HPS-250 | HPS-300 | HPS-350 | HPS-400 | HPS-500 | HPS-600 | ||
| Cap. of Round Bar | 175 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | ||
| Cap. of Square Bar | 125 | 150 | 200 | 250 | 275 | 325 | 350 | 425 | ||
| Stroke | 135 | 135 | 140 | 140 | 140 | 135 | 150 | 150 | ||
| Strokes per min. (approx) | 100-120 | 100-120 | 85-100 | 85-100 | 85-100 | 70-85 | 70-85 | 70-85 | ||
| Blade Size | 12″-14″ | 14″-16″ | 16″-18″ | 18″-20″ | 20″-22″ | 18″-24″ | 24″-35″ | 30″-36″ | ||
| Electric Motor | 1 H.P. | 1 H.P. | 2 H.P. | 2 H.P. | 2 H.P. | 3 H.P. | 5 H.P. | 5 H.P. | ||
| RPM of Motor | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 960 | 960 | ||
| Length | 1000 | 1000 | 1150 | 1250 | 1300 | 1500 | 1650 | 1750 | ||
| Width | 600 | 600 | 625 | 650 | 650 | 675 | 700 | 725 | ||
| Height | 800 | 800 | 1000 | 1000 | 1100 | 1200 | 1300 | 1400 | ||
| Weight (approx.) | 325 kg. | 335 kg. | 450 Kg. | 550 kg. | 650 Kg. | 750 kg. | 1100 Kg. | 1200 Kg. | ||
| Weight with Packing | 400 kg. | 450 kg. | 550 Kg. | 650 kg. | 775 Kg. | 900 Kg. | 1300 Kg. | 1400 Kg. | ||
| V-Belts Required | 4 Pcs. | 4 Pcs. | 4 Pcs. | 4 Pcs | 4 Pcs | 5 Pcs | 6 Pcs | 6 Pcs | ||
HP Singh Machinery Pvt.Ltd is one of the leading expertise in manufacturing and exporting Grinding Machines. We provide these machines in the market at very economical price. Horizontal Spindle Surface Grinding Machines are ideal for components requiring extremely accurate and highly finished flat surfaces, tool room applications.
General Future of 6-8-10-12 Series Introduction
Enlarged, honeycomp-ribbed column, especially suitable for heavy duty grinding.
Guide Ways
These high precision surface grinding have been specially devoloped and improved in recent years. The saddle resets on precision and scraped V and Flat way. These guide ways and grinding wheel head lubrication system is independent
Hand Wheel
Zero-Setting Slip-Rings with vernier on vertical handwheel and vernier on crossfeed handwheel
High Precision Cartridge Wheel Spindle
High precision cartridge type spindle is supported by 2 preloased precision angular contract ball bearing and driven by V3 class motor through flexible coupling that allow accurate grinding performance
Enlarged Column and Base
Enlarged column and base create high atability and rigidity. The height of column is increased up to 16 (400 mm) grom table surface to the center line of spindle
Longitudinal & Cross Drive
The longitudinal Movement is driven by (Electrical / Hydraulic) for 2A, 3A Series the cross movement is driven by motor for accurate increment feeding
| Technical Specifications (IN MM) | |||||
| Descriptions | Model | HPS-618 A, 1A, 2A, 3A ED/HD | HPS-820 A, 1A, 2A, 3A ED/HD | HPS-1024 A, 1A, 2A, 3A ED/HD | HPS-1224 A, 1A, 2A, 3A ED/HD |
| Table Size | 150 x 450 mm (6″ x 18″) | 200 x 500 mm (8″ 20″) | 250 x 600 mm (10″ x 24″) | 300 x 600 mm (12″ x 24″) | |
| Max. Grinding Length | Longitudinal | 475mm (19″) | 525 mm (21″) | 625 mm (25″) | 625 mm (25″) |
| Max. Grinding Width | Crosswise | 160mm (6¼”) | 212 mm (81 / 2″) | 262 mm (101/2″) | 312 mm (12½ ) |
| Max. Distance from Table Surface to Spindle Centerline | 250 mm (10″) | 400 mm (16″) | 450 mm (18″) | ||
| Standard Magnetic Chuck Size | 160 x 350 mm (6″ x 14″) | 200 x 450 mm (8″ x 18″) (250 x 500 mm 10″ x 20″) 300 x 600 mm (12″ x 24″) |
|||
| Longitudinal Movement of Table | Hand wheel per rev | 100 mm (4″) | |||
| Table speed elect. autofeed | |||||
| Max. travel elect. autofeed | 475 mm (19″) | 525 mm (21″) | 625 mm (25″) | 625 mm (31″) | |
| Max. travel hydraulic | |||||
| Table Speed infinitely variable Hydraulic | 50HZ, 5-23 m/min, 60HZ, 5-28 m/min | ||||
| Cross Transverse Travel | Max. Auto transverse travel | 160 mm (6¼) | 212 mm (8½ ) | 362 mm (10½ ) | 312 mm (12½ ) |
| Handwheel per revolution | 5 mm (0.2″) | ||||
| Handwheel per graduation | 0.05 mm (0.0012 ½ ) | ||||
| Auto transverse increment | 1-10 mm (0.04″ – 0.4″) | ||||
| Wheelhead Vertical | Handwheel per revolution | 1 mm (0.05″) | |||
| Handwheel per graduation | 0.01 | ||||
| Grinding Spindle Drive | Power Rating | 1 H.P. | 2 H.P. | ||
| Speed | 50 HZ, 2850 RPM, 60HZ, 3450 R.P.M. | ||||
| Standard Grinding Wheel | Diameter | 178 mm (7″) | 203 mm (8″) | ||
| Width | 12 mm(½” ) | 19 mm (¾ “) | |||
| Bore | 31.78 (1 ½”) | ||||
| Hydraulic Motor | Power Rating | 1 HP x 6 P | 2 HP x 6 P | ||
| Longitudinal Feed Motor | Power Rating | 1 HP x 6 P | 1 HP x 6 P | 2 HP x 6 P | |
| Floor Space | Length x width x height Total space required | 1370 x 1020 x 1845 mm (54″ x 40″ x 73″) | 2030 x 1370 x 11630 mm (80″ x 54″ x 64″) | 2450 x 1550 x 1630 mm (96″ x 61″ x 64″) | 2500 x 1680 x 2500 mm (98″ x 66″ x 98″) |
| Packing Dimensions | L x W x H | 1270 x 920 x 1820mm (50″ x 36″ x 72″) | 1680 x 1270 x 1650 mm (66″ x 50″ x 65″) | 1780 x 1320 x 1650 mm (70″ x 52″ x 65″) | 1780 x 1400 x 1700 mm (70″ x 56″ x 67″) |
HPSM Mechanical Center less grinder is able to faster grinding with better surface finishes, than competing machines. We manufacture, supply and export Mechanical Center less Grinder at best price with high reliability, easy operation, and low maintenance. These grinding machines are an ideal asset to every industry.
Salient Features
Optional Accessories
Standard Accessories
| Technical Specifications | ||||||||
| Particulars | HPS 100 | HPS 150 | HPS 200 | |||||
| Grinding Capacity in mm | 1 to 75 | 1 to 75 | 1 to 75 | |||||
| Grinding Wheel Size | 350 x 700 x 127 | 350 x 700 x 127 | 350 x 700 x 127 | |||||
| Grinding Wheel Speed : R.P.M | 1800 / 2000 | 1800 / 2000 | 1800 / 2000 | |||||
| Regulating Wheel Size | 225 x 100 x 76.2 | 225 x 100 x 76.2 | 225 x 100 x 76.2 | |||||
| Regulating Wheel Speed | 15 x 45 x 100 | 15 x 45 x 100 | 15 x 45 x 100 | |||||
| Power | ||||||||
| Grinding Wheel Motor | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) | 7.5 H.P. ( 10 H.P. Optional ) | |||||
| Regulating Wheel Motor | 1 H.P. | 1 H.P. | 1 H.P. | |||||
| Hydraulic Unit Motor | 1 H.P. | 1 H.P. | 1 H.P. | |||||
| Coolent Pump Motor | 0.10 HP | 0.10 HP | 0.10 HP | |||||
| Power Supply | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 | V / Ac415 / Hz50 / Phase 3 | |||||
Horizontal Boring Machine
| Technical Specifications | |||||||
| Alloy Steel Work Spindle Hardened & Ground Diameter | 80 | 100 | 110 | 125 | |||
| Morse Taper Number | 5 | 6 | 6 | 6 | |||
| Max. Longitudinal Movement of working Spindle(Z-Axis) | 510 | 510 | 510 | 600 | |||
| No. of Spindle Speeds | 9 | 9 | 9 | 9 | |||
| Range of Spindle Speeds-R.P.M | 20to300 | 15to250 | 15to250 | 15to250 | |||
| Longitudinal Work Spindle Feeds Nos. | 9 | 9 | 9 | 9 | |||
| Max. Height of Spindle Axis from Table Surface(Y- Axis) | 925 | 1000 |
1100 |
1250 |
|||
| Min. Height of the Spindle Axis from Table Surface | 25 | 35 | 35 | 35 | |||
| Dimensions of the rotary table | 900*1105 | 1030*1375 | 1100*1450 | 1225*1675 | |||
| Longitudinal Table Traverse(W-Axis) | 1625 | 1775 | 1925 | 2050 | |||
| Long Table Travel Feeds(including one rapid) | 10 | 10 | 10 | 15 | |||
| Transversal Table Travel Feeds | 10 | 10 | 10 | 15 | |||
| Vertical Head Stoke Travel feeds | 4 | 4 | 4 | 15 | |||
| Rotary Table Automatic feeds | 10 | 10 | 10 | 15 | |||
| Max. Cross Movement of the table(X-Axis) | 1000 | 1100 | 1300 | 1550 | |||
| Max. Distance b/w Stay Bearing & Facing Head | 2400 | 2690 | 2800 | 2950 | |||
| Facing Head Diameter | 505 | 555 | 600 | 650 | |||
| Weight Approx in Kgs.(without packing & accessories | 8500 | 10000 | 11000 | 16500 | |||
We have earned considerable reputation in the market as a reliable manufacturer, supplier and exporter of Brake Drum Making Machine. Equipped with advanced components, the body of the machine is fabricated utilizing fine quality material that has great mechanical strength. In addition, our engineers take utmost care to design the offered product in compliance with the quality standards specified by the industry. These machines are widely used for making brake drum and brake shoe for different vehicles.
We are developing and offering a remarkable range of Crank Shaft Grinding Machine. The products we offer are developed by a team of deft engineers, following international norms & guidelines. These grinders find their extensive applications in several sectors like automobile, engineering and construction for varied grinding & reconditioning applications.
Tejinder PAl Singh (H P Singh MAchinery Pvt Ltd)
75 Ganesh Chandra Avenue, , -700013, Kolkata, West Bengal, India
Share us via
View Contact Number
