Standard Accessories :
Cross Slide
Rocker Type Tool Holder front & rear, with one fine adjustment each
Limited Stop for over loading
Tail stock with quill for sleeve collet A-3
Weight operated bar feed length 3.5m.
Motor for main spinlde with jack shaft & V-belt
Feed Motor
Change Gear set (11 Nos.)
Water Coolant Pump
Hydraulic & Roller Blade Guide for long life accurate cutting
Switches & motor fitted in the machine base
Ready for connection Front & rear sheet metal splash guard
Weight & Extra Weight
Rope for bar feed
Pusher rod
Stand bar support head
LN Key set
Tool Tray
Chuck open spanner
Spindle nut's spanner
Double end spanner 6 to 19 & 22x24
Sq. angle box spanner 6mm
Sq. box spanner 6mm
Extra Accessories
Long turning attachment front & rear
Open tool holder front & rear
Extra long Quill
Quill for MT2
Step turning tool holder W-35
Automatic electric shutter
Silent bar feed assembly
| Sr. No. | 1 | 2 | 3 | 4 |
| Max Spindle Capacity for Round Bars for Hexagonal Bars for Square Bars |
25 mm 22 mm 18 mm |
30 mm 26 mm 21 mm |
42 mm 36 mm 29 mm |
60 mm 52 mm 42 mm |
| Distance from collet to face to tail stock | 240 mm | 240 mm | 395 mm | 395 mm |
| Turning Length with Longitudinal Turning Attachment | 70 mm | 70 mm | 100 mm | 100 mm |
| Stroke of cross slide | 22 mm | 22 mm | 43 mm | 43 mm |
| Tail stock travel | 100 mm | 100 mm | 165 mm | 165 mm |
| Max. capacity of tailstock collet | 13 mm | 13 ram | 22 mm | 22 mm |
| Spindle Speed (12 Speed) Min. Max. | 550 4000 |
550 4000 |
200 2500 |
160 2000 |
| Production Rate (Approx) Min. Per Hour Max. | 28 2100 |
28 2100 |
12 1245 |
12 1245 |
| Power Rating of work | ||||
| Spindle Motor (1400/2800 RPM) KW/HP | 1.2/1.6 | 1.2/1.6 | - | - |
| Spindle Motor (700/1400 RPM) KW/HP | - | 2.8/3.5 | 2.8/3.5 | |
| Power Rating of Camshaft Motor (1400 RPM) KW/HP | 0.37/0.5 | 0.37/0.5 | - | - |
| Power Rating of Camshaft Motor (700/1400 RPM) KW/HP | 0.75/1 | 0.75/1 | ||
| Floor Space not including bar feed | 0.48x.081 mtr | 0.48x.081 mtr | 0.8x1.6 mtr | 0.8x1.6 mtr |
| Packing Case | 1.8 cu. mtr. | 2 cu. mtr. | 3 cu. mtr. | 3.6 cu. mtr. |
| Net Weight of Complete Machine | 670 Kgs. | 670 Kgs. | 1250 Kgs. | 1300 Kgs. |
Standard Accessories :
Hydraulic Blade Tension
Auto Saw Frame Height Adjustment
Heavy Duty Reduction Gear Box (Elecon/Shanti)
Stepless Cutting Feed Regulation
Complete Electric System
Complete Coolant System
Driven Chip Brush
Complete Hydraulic System
PLC Control for all Electric & Hydraulic Function
Hydraulic & Roller Blade Guide for long life accurate cutting
Blade Breakage Detector
Extra Accessories
Chip Conveyor
A.C.Drive for Infinitely varible speed control
Job Roller Stand
Bundle Cutting Attachment
Bi-Metal Bandsaw Blade
Variable Vice Pressure for thin walled job
Wire Brush
Bar Stand
| Sr. No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | |
| Cutting Capacity Round (mm) | 250 | 300 | 350 | 425 | 530 | 650 | 800 | 1000 | 1250 | 1500 | |
| Cutting Capacity Square (mm) | 250 X 250 | 300 X 300 | 350 X 350 | 425 X 425 | 530 X 530 | 650 X 650 | 800 X 800 | 1000 X 1000 | 1250 X1250 | 1500 X 1500 | |
| Blade Dimension | 3760X27X0.90 | 4100X34X1.10 | 4420X34X1.10 | 4860X41X4.30 | 5800X54X1.30 | 6900X54X1.60 | 8000X67X1.60 | 8800X67X1.60 | 12300X80X1.60 | 13100X80X1.60 | |
| Blade Speed | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | |
| Power Required | Saw Drive | 1.50/2.00 | 2.20/3.00 | 3.70/5.00 | 5.50/7.50 | 7.50/10.00 | 9.30/12.50 | 15.00/20.00 | 15.00/20.00 | 15.00/20.00 | 15.00/20.00 |
| Kw/Hp 440 V AC | Hyd.Drive | 0.75/1.00 | 0.75/1.00 | 0.75/1.00 | 1.75/1.00 | 1.75/1.00 | 1.50/2.00 | 1.50 / 2.00 | 2.25/3.00 | 2.25/3.00 | 2.25/3.00 |
| 50Hz 3 Phase | Coolant Pump | 0.12/0.16 | 0.12/0.16 | 0.12/0.16 | 0.12/0.16 | 0.12/0.15 | 0.12 / 0.16 | 0.12 / 0.16 | 0.12 / 0.16 | 0.12 / 0.16 | 0.12/0.16 |
| Hyd.Tank | Litre | 40 | 50 | 60 | 60 | 80 | 80 | 80 | 130 | 130 | 130 |
| Coolant Tank | Litre | 60 | 60 | 60 | 60 | 80 | 80 | 80 | 130 | 130 | 130 |
| Apprx Dia | (Semi Auto) | 2 X 1 X 1.3 | 2.3 X 1 X1.3 | 2.3 X 1 X 1.3 | 2.5 X 1 X X1.7 | 3.3 X 1.4 X2.3 | 4.0 X 1.5 X 2.5 | 4.6 X 1.7 X 2.9 | 5.0 X 1.9 X 3.5 | 5.0 X2.0 X4.0 | 6.0 X2.0 X4.0 |
| Weight (Approx in Kg.) | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 | 00.00 |
|
Standard Accessories :
Gear Box : Elecon /Shanti Make
Gear Box Oil
Job Stopper, VBlet & Pulley
Electric Drive Motor, Coolant Pump,
Contractor Push Button
Extra Accessories
Roller Stand
Bi-Metal Bandsaw Blade
Carbon Steel Bandsaw Blade
| Sr. No. | 1 | 2 | 3 | 4 | 5 |
| Round (MM) | 200 | 300 | 350 | 400 | 450 |
| Square (MM) | 150 x 150 | 250 X 250 | 300 X 300 | 350 X 350 | 400 X 400 |
| Drive Motor | 1 HP (1440 RPM) | 2 HP (1440 RPM) | 2 HP (1440 RPM) | 2.5HP (1440 RPM) | 3 HP (1440 RPM) |
| Coolant Pump | 0.15HP 440 Vit | 0.15HP 440 Vit | 0.15HP 440 Vit | 0.15HP 440 Vit | 0.15HP 440 Vit |
| Blade Speed | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 | 20-40-60 |
| Blade Size | 3000 X 27 X0.9 | 3760 X27 X0.9 | 4100 X 34 X 1.1 | 4420 X 34 X 1.1 | 4570 X 41 X 1.1 |
| Net Weight (Aprox.) | 350 | 575 | 675 | 725 | 800 |
| Dimension (H x L x W) | 1.1 X1.8 X1.4 | 1.1 X 2.4 X 0.8 | 1.2 X 2.6 X 0.8 | 1.2 X 2.6 X 0.8 | 1.5 X 2.7 X 1.0 |
Extra Parts :
Coolant Pump One Set. (Coolant Pump, Tank, Inter adjustable, Stainless Steel Pipe. Outlet Pipe, Valve, etc.)Collet 3 to 12 mm rice (Total Collets - 6 nos.)
| Sr. No. | 1 | 2 |
| Spindle RPM | 1800 rpm | 0 - 2200 rpm |
| Shaft Clamping Dia | 12mm-70mm | 12mm-100mm |
| Length of Key-Way | 5 mm-150 mm | 5 mm-200 mm |
| Key-Way Size | 3 mm-13 mm | 3 mm-16 mm |
| Standard Collet | ER - 20 | ER - 25 |
| Power Required | 1 HP / 0.75 KW | 1.5 HP/1.12 KW |
| Approx. Weight (in. Kg.) | 500 | 625 |
| Standard Accessories :For Light Duty & Medium Duty Lathe Machine Only |
| Chuck Back Plate, Spindle Sleeve, 2-Dead Centre, Change Gear Set, Tool Post, Spanner Switch, Stand Motor Pulley. |
| Standard Accessories :For Heavy Duty Lathe Machine Only |
| Steady Rest, Follow Rest, Face Plate, Chuck Back Plate, Spindle Sleeve, 2 Dead Centre, Change Gear Set, Tool Post, Spanner Switch, Stand Motor Pulley. |
| Sr. No. | Size | Approx Weight |
| 1 | 4.6 Feet | 450 Kg |
| 2 | 5.3 Feet | 470 Kg |
| 3 | 6.0 Feet | 500 Kg |
Specification for all types of Lathe Machine
|
Specification |
Light Duty |
Medium Duty |
Heavy Duty |
|
Height of Centre |
165 mm |
215 mm |
254 mm |
|
Swing over Bed |
325 mm |
425 mm |
490 mm |
|
Bed Width |
238 mm |
279 mm |
325 mm |
|
Length of Gap in Bed |
110 mm |
110 mm |
150 mm |
|
Spindle Bore |
40 mm |
52 mm |
52 mm |
|
Lead Screw Diameter & Pitch |
25.4 mm x 4 TOI |
31.75 mm x 4 TOI |
38.1 mm x 4 TOI |
|
Metric |
19/0.50 to 8.0 mm |
19/0.50 to 8.0 mm |
13/1 to 6 mm |
|
Inch |
23/4 to 40 TPI |
23/4 to 40 TPI |
19/2 to 24 TPI |
|
Motor |
1 HP / 1440 RPM |
2 HP / 1440 RPM |
2 HP / 1440 RPM |
Standard Accessories :
Motor Pulley
Clutch Key
Clutch Key Springs
Slide Adj. Spanner
Fly Wheel & Gear Guard
Oil Cup for Lubrication Point
Knock-out System
| Sr. No. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | |
| Tonnage | Ton | 10 | 20 | 30 | 50 | 75 | 100 | 150 | 200 | 250 |
| Stroke Adjustment | m.m. | 6-51 | 10-76 | 10-76 | 13-102 | 13-115 | 13-127 | 13-140 | 13-152 | 13-165 |
| Adjustment of Ram | m.m. | 25 | 38 | 38 | 45 | 45 | 51 | 51 | 51 | 51 |
| Crank Shaft Dia (At Main Bearings) | m.m. | 63 | 76 | 83 | 95 | 115 | 127 | 152 | 160 | 165 |
| Bed of Ram | m.m. | 215 | 225 | 290 | 355 | 375 | 420 | 445 | 470 | 485 |
| Hole of Ram | m.m. | 25.4 | 32 | 38 | 38 | 45 | 51 | 51 | 63 | 63 |
| Size of Bed (LR. x FB.) | m.m. | 355x460 | 457x508 | 508x559 | 559x610 | 610x813 | 660x762 | 711x914 | 762x965 | 812x1016 |
| Opening in Bed | m.m. | 82 | 89 | 108 | 132 | 203 | 210 | 222 | 236 | 300 |
| Thickness of Bolester | m.m. | 55 | 63 | 63 | 76 | 89 | 102 | 102 | 115 | 127 |
| Opening in Bolester (Dia.) | m.m. | 76 | 82 | 102 | 125 | 198 | 203 | 215 | 230 | 250 |
| Fly Wheel Dia. | m.m. | 425 | 508 | 558 | 660 | 812 | 914 | 1016 | 1065 | 1220 |
| Stroke Per Minute | m.m. | 70 | 60 | 60 | 55 | 50 | 40 | 30 | 30 | 25 |
| Electric Motor (1440 Rpm) | m.m. | 1 | 2 | 3 | 5 | 7.5 | 10 | 15 | 20 | 25 |
| Floor to Top of Bed | m.m. | 720 | 750 | 750 | 800 | 875 | 863 | 863 | 863 | 863 |
| Height | m.m. | 1450 | 1650 | 2050 | 2650 | 3125 | 3375 | 3550 | 3975 | 4125 |
| Left to Right | m.m. | 610 | 725 | 775 | 1050 | 1225 | 1425 | 1650 | 1975 | 2120 |
| Front to Back | m.m. | 775 | 925 | 1025 | 1350 | 1625 | 1875 | 2050 | 2250 | 2300 |
| Approx. Weight | Kg. |
Standard Accessories :
Elec. Control Panel & Production Counter
Hydraulic Overload Safety
Motorized Side with Brake Motor & Die Height Indicator
'SMC/FESTO' make FRL & Pneumatic Fittings
Motorized Grease Lubrication
Slide Knockout Device, 4 Way Cam Limit Switch.Anti-repeat Safety Device
PLC Control System
Misfeed Detector Socket
ROSS / Toyoki Japan make Solenoid Valve
Optional Accessories
Variable Stroke
Pneumatic Die Cushion
Photo Safety Guards
Variable Speed
Anti-vibration Mounts
| Sr. No. | 1 | 2 | 3 | 4 | 5 |
| Capacity in Tons | 110 | 160 | 200 | 250 | 315 |
| Variable (Optional) | 10-120 | 10-160 | 10-160 | 10-160 | 10-160 |
| Area of Bolster (LR x FB) | 740x680 | 820x760 | 820x760 | 1020x850 | 3250x1250 |
| Thickness of Bolster 1 | 100 | 120 | 120 | 150 | 150 |
| Shut Height (SDAU) | 450 | 500 | 500 | 550 | 600 |
| Ram Area | 650x500 | 700x550 | 700x500 | 850x630 | 1000x800 |
| Ram Adjustment | 80 | 90 | 90 | 100 | 125 |
| Floor to Top of Bolster | 900 | 900 | 900 | 1000 | 1000 |
| Stroke per Minute | 40 | 30 | 30 | 25 | 25 |
| Floor Space Required | 1120x1490 | 1220x1600 | 1220x1600 | 1490x1790 | 1740x900 |
| Main Motor HPxP | 10x4 | 15x4 | 20x4 | 25x4 | 30x4 |
| Slide Adjustment Motor HPxP | 0.75x4 | 1x4 | 1x4 | 1.5x4 | 2x4 |
| Overall Height | 3100 | 3290 | 3290 | 3600 | 4500 |
| Approx. Weight | 6000 | 8000 | 10000 | 18000 | 24000 |
Extra Accessories
Foot Switch for Single PH. 2 Motor
Foot Switch for Three PH. 2 Motor
Vearsabal Speed Driver - 1 / 2 / 3 HP.
| Sr. No | Working Widht | Thickness | Approx Weight |
| 1 | 605 mm | 2 mm/14 Swg | |
| 2 | 1000 mm | 1.6 mm/16 Swg | |
| 3 | 1295 mm | 1.6 mm/16 Swg |
Forming is process to bend the sheet / strip as per design or drawing. The blank of sheet is passed between roll former to achieve the desired shape without any variation or change in thickness. Wide rang of machine helps customer to select the machine as per job requirement. The lin is supplied with attachments which facilite to get finished products at end with desired length.
