1 Products availableWe are leaders in the market for providing best range of Hydraulic Press Brake, Power Press, H Type Power Press, Pillar Type Power Press Machine and Power Press Manufatcurer
Ram travel repeatable within 0.03mm for consistent bends for interchangeable output. Ram travels is referenced from bed to avoid side frame deflections affecting stroke accuracy.
Rugged structure from ultra tested Is 2062plates, rigidity conforming to international standards. Hydraulic, electricals of internationally reputed brands for consistent performance and reliable operation. Front operated manually back gauge front sheet supports with scale Most hydraulic parts rated for 310 bar but working pressure only 160 bar for long life, reliable operation. Ram guides of 4-piece design with replaceable liners. Pivots with permanently lubricated bearings or hardened parts lubricated by central hand pump Cylinders of ultra-tested seamless honed tubes, hard chrome-plated pistons, dual seals )Telfon ring plus set of chevron packings) for extra reliability. 3-speed bending cycles for faster output yet slow smooth bending with minimal shock loads. Movable control station with majority controls, emergency stop, up-down foot-switch controls, Inch cycle mode for set-up and one-off jobs. Single cycle modes for repeat cycles, production runs.
Main cylinders seals can be easily replaced without requiring crane of dismantling the ram. Hydraulic powder gives silent working, better safety against overload, instant stoppage-reversal of ram One set of unhanded standard punch, multi-V die Block Lifting chains system and rotation of die block when using multi-vee die block.
We are offering c type power press we are the manufacturer of fmt brand c type power press from the range of 5 ton to 400 ton.
We are the manufacturer of “fmt” brand power press from the range of 5 ton to 200 ton.
We have manufacturer of power press machine from the range of 05 ton to 200 ton.
we offer a wide range of " fmt" brand c type or mechanical power press to our customers. these products are manufactured using up- grade components. these products have the production capacity of which ranges from 5 ton to 200 ton. our clients can avail these machine in various sizes and lengths as per the clients specifications. availability : design fixed inclined geared ungeared stroke fixed adjustable clutch mechanical pneumatic features : long service life consistent performance high quality resistance to corrosion requires low maintenance used for : cutting bending punching embossing
We are offering pneumatic clutch power presses are fabricated from high grade raw materials for assuring their supefrior quality & accuracy in their operation.
We are offering power press machine 50 ton h-type. we have a "fmt" brand power press from the range of 05 tons to 200 tons. Our "fmt" brand power press fabricated machine using steel plate body. Our clients can avail best quality products from us at cost efficient prices. All heavy jobs can .
We are offering to sell an extensive range of Pillar Type Power Press with following features: - Easy usage - Efficient functioning - Less maintenance View complete details
We are manufacturer of "fmt" Brand Power Press 05 to 200 Ton. We manufacture presses as per your requirement like any modification in the body or centre or tie rods or the stroke length.
We are Manufacturer, Suppliers, Exporters of "FMT" Brand Power Press : Pillar Type 50 Ton Power Press, C-Type Power Press, Single point power press, High speed power press, H-type Power press, Cross shaft Power Press, Pillar Type Power Press etc. Kindly contact us.
FMT Power Press is the leading supplier of the H type Power Press Machine. H type power press is Mechanical Power Press Machine. It produce in the capacity from 5 tons to 200 tons. Features of C type power press such as SingleDouble or Un-geared versions, knockout electronics safety manualautomation lubrication systems. This power press machine is highly suitable for making the components for automobile, electrical and various industrial machines.
We are manufacturer of power press machines , . "fmt" brand "c type" power press, "h type" power press, and "pneumatic" power press from the range of 5 tons to 200 tons. We are in this trend since last 35 years due to quality, workmanship & accuracy.
We have a vast range of FMT Brand Piller H Type Power Press with us, which have steel plate body. Our customers can avail bulk orders as per their capacity, drawings and dimensions. These machines fulfills varied jobs such as mechanical, Electromagnetic, Pneumatic and others. The production range capacity is from 5 to 200 ton and can be avail at reasonable cost from us. Our products are assured for their durability, reliability and performance as they are regularly inspected by our expert engineers.
We are a manufacturer of pneumatic clutch power press machine from the range of 5ton to 200ton.
we offer Pneumatic Power Press Machine.We offer great sales & Services on every machine. We sell Our customers are quite satisfied with the product quality, timely delivery and the most effective prices. We would like to have business.
We are a manufacturer of power press machine as per your requirement like any modification in the body or center or tie rods or the stroke length. At "fmt", we always welcome orders for any press of any capacity & as per your drawing & diemnsion.
We are offering mechanical power press c-type & h-type. we manufacture brand power press as per your requirement like any modification in the body or center or tie rods or the stroke length. At we always welcome orders for any press of any capacity and as per your drawing & dimension.
We are a manufacturer of "fmt" Brand Power Press Machine C-Type & H-Type. We offer great sales & services on every machine. We sell our customers are quite satisfied with the product quality, timely delivery. Kindly contact us. View complete details.
We deliver optimum quality C-Type Power Press to our clients. The production capacity of this machine ranges from 5 ton to 200 Ton. This machine is inspected right from the procurement of the raw material to the final delivery to the clients by the team of experts. To meet the clients requirement, Our C-Type Power Press is made available to them in various lengths and dimensions. Hence, we are counted as the leading Manufacturer, Exporter and Supplier of C-Type Power Press.
Availability :
Frame : The frame is fabricated from solid steel plate with heavy cross ribbing, the structure is designed for perfectly balanced distribution of stress over the cross section eliminating deflection & vibration, in result increased tool & machine life.
Clutch : The Clutch is made of special alloy steel, The pin / rolling key is manufactured from W.P.S. / EN24 material & with proper heat treatment to ensure trouble free long life & give continues stroke for mass production.
Crank Shaft : The Crank shaft is made of special alloy steel & precisely machining it to grind finish & fitted in Graded Gun-Metal Bushes for smooth working, longer life & accuracy.
Adjustables Stroke : The unique feature of adjustable stroke enables the press to perform all kinds of operations by employing short stroke for blanking and forming operation.
Flywheel : Properly sized flywheel is made of high grade cast iron, for storing and releasing adequate energy for the pressing operation, and properly balanced for smooth running.
Gears : The Gears are made of steel cast or fabricated. Gear teeth are generated by precision hobbing machine.
Ram Slide : Ram Slides is made of high grade heavy duty cast iron & properly seasonal & fitted with Hylum Sheet on back side for friction free travel through slides, ensuring longer life of die and easy operation.
Bed : Bed is made of high grade heavy duty cast iron & properly seasoned & properly aligned with ram to obtain high accuracy and precision press operation.
Lubrication : An efficient shot lubrication system has been provided for lubricating the sliding surfaces and moving parts. The lubricant is applied by hand pump.
Oil cups & Grease point are provided for lubricating the sliding surfaces & moving parts. 50 ton & above Hand operated pump provided. Also Automatic lubrication system offered against request.
Standard Accessories
Motor pulley
Slide Adj. Spanner
Fly wheel & Gear guard
Oil cups for lubrication point
Knock-out system
Optionam Accessories
Tow hand operated clutch
Single / continuous stroke
Automatic lubrication pump
Electric Motor, Starter and V-belts
Extra base plate
Inclinable Type
Specifications :
Capacity | Tons | 5 | 10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | 125 | 150 | 200 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Diameter of Crankshaft | MM | 70 | 88 | 115 | 130 | 135 | 140 | 150 | 160 | 170 | 180 | 190 | 250 |
Adjustment of Stroke | MM | 15 x 38 | 15 x 50 | 15 x 63 | 76 | 76 | 89 | 100 | 115 | 130 | 135 | 150 | 150 |
Adjustment of Ram | MM | 19 | 25 | 38 | 51 | 51 | 63 | 63 | 76 | 80 | 90 | 100 | 125 |
Punch Hole in Ram | MM | 25 | 25 | 32 | 38 | 38 | 45 | 45 | 50 | 50 | 50 | 80 | 80 |
Hole in Bed | MM | 57 | 63 | 76 | 82 | 89 | 95 | 101 | 115 | 130 | 150 | 175 | 200 |
Length of (Bolster) | MM | 355 | 432 | 534 | 585 | 635 | 685 | 712 | 738 | 891 | 916 | 1041 | 1100 |
Width of (Bolster) | MM | 178 | 228 | 305 | 355 | 355 | 406 | 457 | 508 | 612 | 662 | 737 | 817 |
Thickness of (Bolster) | MM | 50 | 58 | 63 | 70 | 76 | 83 | 88 | 95 | 114 | 117 | 127 | 137 |
Dist between bed to Ram | MM | 177 | 204 | 250 | 292 | 320 | 350 | 380 | 380 | 406 | 431 | 457 | 482 |
Flywheel Dia. | MM | 406 | 458 | 482 | 533 | 584 | 660 | 762 | 812 | 863 | 915 | 965 | 1016 |
Strokes per minute | MM | 80 | 70 | 45 | 40 | 35 | 35 | 30 | 30 | 30 | 30 | 25 | 25 |
H.P. Required | - | - | - | - | - | - | - | - | - | - | - | - | |
For Geared (1440 RPM) | H.P. | 1 | 1 | 2 | 3 | 4 | 5 | 7.5 | 10 | 10 | 12.5 | 12.5 | 15 |
For Ungeared (960 RPM) | H.P. | 1 | 1 | 2 | 3 | - | - | - | - | - | - | - | - |
Weight Approximate | Kgs. | 400 | 600 | 1100 | 1400 | 1900 | 2400 | 2700 | 3200 | 4700 | 5700 | 6200 | 7700 |
two hand push button controlled operator control panel board (off, inch, single & continues stock) foot switch operation manual lubrication system.
optional accessories:the clutch is made of special alloy steel, the pin / rolling key is manufactured from w.p.s. / en24 material & with proper heat treatment to ensure trouble free long life & give continues stroke for mass production.
Specifications
CAPACITY IN TONS | 10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 | 150 | 200 | |
---|---|---|---|---|---|---|---|---|---|---|---|
Crankshaft Diameter | MM | 88 | 115 | 130 | 135 | 140 | 150 | 160 | 170 | 190 | 250 |
Adjustment of Stroke | MM | 15x50 | 15x63 | 76 | 76 | 89 | 100 | 115 | 130 | 150 | 150 |
Adjustment of Ram | MM | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
Punch Hole in Ram | MM | 25 | 32 | 38 | 38 | 45 | 45 | 50 | 50 | 80 | 80 |
Hole in Bed | MM | 76 | 82 | 89 | 95 | 101 | 115 | 130 | 150 | 200 | 225 |
Bed Size (Length x Width) | MM | 432 x 228 | 534 x 305 | 585 x 355 | 635 x 355 | 685 x 406 | 712 x 457 | 738 x 508 | 891 x 612 | 1041 x 737 | 1100 x 817 |
Bed Thickness | MM | 58 | 63 | 70 | 76 | 83 | 88 | 95 | 114 | 127 | 137 |
Dist.between bed to Ram | MM | 204 | 250 | 292 | 320 | 350 | 380 | 380 | 406 | 457 | 482 |
Flywheel Dia. | MM | 458 | 482 | 533 | 584 | 660 | 762 | 812 | 863 | 965 | 1016 |
Strokes per minute | MM | 70 | 55 | 50 | 45 | 45 | 40 | 40 | 35 | 30 | 25 |
H.P.Required | MM | ||||||||||
For Geared(1440 RPM) | HP | 1.5 | 2 | 3 | 4 | 5 | 7.5 | 10 | 10 | 12.5 | 15 |
For Ungeared(960 RPM) | HP | 2 | 3 | 5 | |||||||
Air Pressure Require | Bar | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
Floor To Top of Bed | MM | 830 | 830 | 880 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
Allover Size LR x FB x H | MM | 800 x 800 x 1900 | 1000 x 1000 x 2100 | 1000 x 1100 x 2200 | 1100 x 1200 x 2400 | 1200 x 1300 x 2500 | 1300 x 1350 x 2650 | 1500 x 1500 x 2750 | 1750 x 1750 x 2900 | 2050 x 2000 x 3300 | 2200 x 2150 x 3500 |
Weight Approximate | Kg. | 600 | 600 | 1500 | 1900 | 2500 | 2700 | 3200 | 5500 | 6500 | 8000 |
Note :
FMTbrand Heavy Duty mechanical Power Presses are coming in "C" frame versions from 5 tons to 200 tons capacity in most economical type of construction with several std./optional features such as manual/auto lubrication systems, knockouts electronics safety, Single/Double or Un-geared versions as also Pneumatic feeders/straightness & die-coilers for automatic Purpose.
FRAME:The frame is fabricated from solid steel plate with heavy cross ribbing, the structure is designed for perfectly balanced distribution of stress over the cross section eliminating deflection & vibration, in result increased tool & machine life.
CLUTCH:The Clutch is made of special alloy steel, The pin / rolling key is manufactured from W.P.S. / EN24 material & with proper heat treatment to ensure trouble free long life & give continues stroke for mass production.
CRANK SHAFT:The Crank shaft is made of special alloy steel & precisely machining it to grind finish & fitted in Graded Gun-Metal Bushes for smooth working, longer life & accuracy.
ADJUSTABLE STROKE:The unique feature of adjustable stroke enables the press to perform all kinds of operations by employing short stroke for blanking and forming operation.
LUBRICATION:An efficient shot lubrication system has been provided for lubricating the sliding surfaces and moving parts. The lubricant is applied by hand pump.Oil cups & Grease point are provided for lubricating the sliding surfaces & moving parts. 50 ton & above Hand operated pump provided. Also Automatic lubrication system offered against request.
RAM SLIDES:Ram Slides is made of high grade heavy duty cast iron & properly seasonal & fitted with Hylum Sheet on back side for friction free travel through slides, ensuring longer life of die and easy operation.
FLYWHEEL:Properly sized flywheel is made of high grade cast iron, for storing and releasing adequate energy for the pressing operation, and properly balanced for smooth running.
BED:Bed is made of high grade heavy duty cast iron & properly seasoned & properly aligned with ram to obtain high accuracy and precision press operation.
GEARS:The Gears are made of steel cast or fabricated. Gear teeth are generated by precision hobbing machine.
We are manufacturer of "FMT" Brand Costomized Power Press Machine C-Type & H-Type (Pillar Type) from the range of 05 Tons to 200 Tons. FMT Brand fabricated steel plate body C-Type & H-Type Power Press for the best quality & precise work with choice of mechanical / Pneumatic clutch suitable for your heavy job.
