1 Form A, 5A 5VDC SPST Slim Power Relays - ALDP105W

Features:-

• Nominal switching capacity: 5A 277V AC
• Excellent heat resistance and tracking performance
• Slim type: 20.5 (L) 7.2 (W) 15.3 (H) mm
• Class B and F coil is available
• Contact rating at 105C 221F is approved by UL/C-UL and VDE (Class F coil only) 6. Clearance and Creepage

Applications :-

• Boilers
• Air conditioner
• Refrigerator
• Hot water units
• Microwave ovens
• Fan heaters

10Amp SPST 1 Pole 24 Vdc General Purpose Relays -G5Q-1A4-EL2-HA-DC24

Features :-

• IEC/EN 60335-1 conformed.
• Coil insulation system: class F (UL1446)
• Type G5Q-EL] Higher performance compare with G5Q standard type. Minimum 100, 000 operations durability at 10 A (250 VAC) switching.
• Type G5Q-EL2] High inrush capacity performance (Inrush current 40 A). UL508 TV3 conformed.
• Type G5Q-EL3] Ideal for motor switching 3 A with high inrush 30 A

Applications :-

• Home appliances
• Building automation
• Lighting control
• Output of control system
• Factory Automation I/O module
• Power supplies
• Inverters
• Temperature controls

General Purpose Relays 16A SPST-NO 12VDC-G2RL-1A-E-DC12V

Features :-

• A wide variety of single pole, double pole, high-capacity (16 A) type and high-sensitivity type (250 mW) Relays are available.
• Low profile; 15.7 mm max. in height.
• Conforms to VDE (EN61810-1), UL508 and CSA22.2.
• IEC/EN 60335-1 conformed. (-HA Model)
• Satisfies ambient operating

Applications :-

• Home appliances
• OA equipments
• Industrial machinery

10Amp 12VDC SPDT PCBPower Relays - JW1FSN-DC12V

Features:-

• Miniature package with universal terminal footprint
• High dielectric withstanding for transient protection: 10, 000 V surge
• ins between coil and contact
• Sealed construction
• Class B coil insulation types available
• TV rated (TV-5) types available
• Sockets are available

Applications:-

• Home appliances TV sets, VCR, Microwave ovens
• Office machines Photocopiers, Vending machines
• Industrial equipment NC machines, Robots, Temperature controllers

4A 24VDC DPST-NO, DPST-NC Non Latching S Series Power Relay - S2-24VDC

Features :-

• Ability to provide wide-ranging control
• High reliability and long life
• Low thermal electromotive force
• Strong resistance to vibration and shock
• Compact with high sensitivity
• Latching types available

Applications :-

• Telecommunications equipment
• data processing equipment
• facsimiles
• alarm equipment
• measuring equipment

10Amp1 Form C 5Vdc General Purpose SPDT Power Relays - ALQ105

Features :-

• Compact with high capacity: 1 Form A and 1 Form C, 10 A
• High surge voltage: 8, 000 V between contacts and coil
• Miniature size and small: 10(W) 20(L) 16(H) mm
• High breakdown voltage: 4, 000 V between contacts and coil
• Ambient temperature: 40C to +85C

Applications :-

• Household appliances: Air conditioners, Refrigerators, Fan heaters, Microwave ovens, Inverter and Hot water units

Features :-

• IEC60335-1* compliant type available
• Certified by UL/C-UL, VDE
• Low profile type available (h = 15.8 mm .622 inch)
• Reflow possible (pin-in-paste)
• 2. Inrush type available

Applications :-

• Industrial equipment
• Home appliances
• Lighting control equipment
• Security equipment
• Various power supplies
• Smart meters

Features :-

• Contributes to device energy savings with latching type.
• UL/C-UL approved
• CD-free , PB -free
• High insulation
• 30Amp capacity in small size
• Sealed Constructions

• Low sound pressure level
• Plastic sealed type
• Low temperature rise
• Wide line up
• Compact and High capacity 20A Load Switching

Features :-

• Contact arrangement: 2 Form A
• Compact size (L: 41.0 W: 50.0 H: 39.4 mm
• Contributes to energy saving in devices thanks to reduced coil hold voltage

Applications :-

• Battery charge and discharge systems
• Inverter control, DC load control
• Photovoltaic power generation systems

Features :-

• Long insulation distance
• High capacity
• Coil holding voltage contributes to saving energy of equipment
• Contact gap: 1.5 mm .059 inch and 1.8 mm*** .071 inch

Features :-

• Wide switching range From 100A 100 mV DC to 4 A 250 V AC
• Dual-In-Line packaging arrangement
• A variety of contact arrangements 2 Form A 2 Form B, 3 Form A 1 Form B, 4 Form A
• High shock and vibration resistance Shock: 50 G Vibration: 10 to 55 Hz at double amplitude of 3 mm
• High sensitivity in small size 100 mW pick-up and 200 mW nominal operating power

Applications :-

• Telecommunications Equipment
• Data Processing Equipment
• Facsimiles
• Alarm Equipment
• Measuring Equipment

Features :-

• High Breakdown Voltage
• Sockets are available
• High switching Capability
• Wide variation
• High Sensitivity

Features :-

• Sealed construction
• Class B coil insulation types available
• VDE, TV, SEMKO, SEV, FIMKO, TV-5 also approved
• Miniature package with universal terminal footprint
• Class B coil insulation types available

Applications :-

• Office Machines- Photocopiers, Vending machines
• Home Appliances -TV sets, VCR, Microwave ovens
• Industrial Equipment -NC machines, Robots, Temperature controllers

Features :-

• High dielectric withstanding for transient protection
• TV rated (TV-5) types available (only for 1 Form A type)
• Sockets are available
• Miniature package with universal terminal footprint
• Sealed construction

Applications :-

• Industrial equipment NC machines, Robots, Temperature controllers
• Home appliances TV sets, VCR, Microwave ovens
• Office machines Photocopiers, Vending machines

5 Amp 24 Vdc DPST NO Sealed Small PolarizedPower Relays - DSP2A-DC24V

Features :-

• Latching types availble.
• Compact with high contact rating
• High Sensitivity
• Sockets are available
• High switching capability

Applications :-

• Measuring Instuments
• Office and Industrial Electronic devices
• NC machines , Temerature Controllers and PLC
• Terminal devices of Information processing equipmements

Features :-

• High Sensitivity
• Latching types availble.
• High switching capability
• Compact with high contact rating
• Sockets are available

Applications :-

Features :-

• High capacity and small size
• Sockets are available
• Compact and Slim 20mm(L) X 10MM(W) X 16mm (H)
• Outstanding Shock resisatnce
• Twin conatct structure

Applications :-

• Interface relays for factory automation and communication equipment
• Programmable controllers
• Output relays for measuring equipment , timers, counters & temperature controllers

Features :-

• Low power consumption (200 mW).
• Max size 20.5L x 7.2 W x 15.3 W mm.
• UL recognized / CSA certified. VDE Approved
• Standard models switch up to 3 A High-capacity models switch up to 5 A (AC loads only)

Applications :-

• Air Conditioners
• Water Heaters
• Small Electric Appliances
• Refrigerators

Features :-

• High Switching Capacity
• 4, 000 V high breakdown volatge & 6, 000 V high surge breakdown voltage
• Sealed construction allows automatic washing
• High density mounting with 5mm .197 inch Width
• 1 form A & 1 form C contcat arrangement with options for a variety of applications.

Applications :-

• Industrial Equipment & Office Equipment
• Interface relays for programmable controllers.
• Household Appliances
• Output relays for measuring equipments , timers , counters & temperature controllers.

Features :-

• IEC/EN 60335-1 conformed. (-HA Model)
• A wide variety of single pole, double pole, high-capacity (16 A) type and high-sensitivity type (250 mW) Relays are available
• Satisfies ambient operating temperature requirement of 85C and 105C (-CV Model).
• Clearance and creepage distance: 8 mm / 8 mm min.
• Low profile; 15.7 mm max. in height

Applications :-

• OA equipments
• Industrial machinery
• Home appliances

Features :-

• Contact arrangement: 2 Form A
• Compact size (L: 41.0 W: 50.0 H: 39.4 mm
• Contributes to energy saving in devices thanks to reduced coil hold voltage

Applications :-

• Battery charge and discharge systems
• Inverter control, DC load control
• Photovoltaic power generation systems

4 Amp 12 Vdc3 Form A & 1 Form BPanasonicGeneral Purpose Relay, S Series, Power Relay -S3-12Vdc

Features :-

• High reliability and long life
• Latching types available
• Low thermal electromotive force
• Compact with high sensitivity
• Strong resistance to vibration and shock

Applications :-

• Facsimiles
• Telecommunications Equipment
• Alarm Equipment
• Data Processing Equipment
• Measuring Equipment

Features :-

• High sensitivity: 200 mW nominal operating power
• Sockets are available
• Compact with high capacity
• Complies with safety standards
• High breakdown voltage

Features :-

• HIgh capacity and long life
• Terminals are available
• Excellent Surge Resistance
• Compatible with all major safety standards
• Excellent resistance to conatct welding

Applications :-

• Industrial Equipments
• Home Appliances
• Office Equipments

16 Amp 277Vac 1 Form A 1Coil Latching 5VDC General Purpose Relays -ADW1105HTW

Features :-

• Breakdown voltage (between contact and coil): 5, 000 V
• Inrush current 100A type available
• Surge breakdown voltage (between contact and coil): 12, 000 V
• Reflow possible (pin-in-paste)
• IEC60335-1* compliant, PTI 325V (VDE approved) type available
• Creepage distance and clearances between contact and coil: 6 mm

Applications :-

• Security equipment
• Various power supplies
• Smart meters
• Industrial equipment
• Home appliances
• Lighting

Double-Pole 5 Amp 240Vac DPDTNon Latching typeG2R Series make OmronGeneral Purpose Power Relay -G2R-2-AC240

Features :-

• Safety-oriented design with dielectric strength of 5, 000 V between coil and contacts, and surge resistance of 10, 000 V
• 1General purpose power Relays of single-pole10 A and double-pole 5 A
• AC and DC types are both available for operational coils.

Applications :-

• Home Appliances
• Industrial

2AMP, 5VDCDPDT (2 Form C)Low Signal Relays G6SK-2-DC5

Features:-

• Compact, Industry-Standard 2-pole relay, designed to switch
• 2A Signal Loads.
• Long terminals for ideal for soldering and mounting
• reliability. (Surface mounting terminal models)
• Space-saving inside-L terminal. (Surface mounting terminal
• models)
• Unique terminal structure, designed to withstand IRS
• soldering processes. (Surface mounting terminal models)
• High dielectric strength (2, 000 VAC) and impulse withstand
• voltage between coil and contacts (2, 500 V, 2 10 s:
• Telcordia requirements).
• Ultra-miniature at 9.4 mm (H) 7.5 mm (W) 15 mm (L).
• Models available with BSI (EN62368-1) supplementary
• insulation certification. (-Y type)

Applications:-

• Telecommunication equipment
• Measurement devices
• Office automation machines
• Audio-visual products.
• Security equipment
• Building automation equipment
• Industrial equipment
• Amusement equipment
• Home appliances

Signal Relays

Features :-

• 1 Form C / 2 Form C contact
• DIL terminal array enables use of IC sockets
• Available 2 coil latching type

Applications :-

• Office Equipment
• Industrial Equipment
• Telecommunications and Measuring Devices
• Computers and related Equipment

Features :-

• High sensitivity single side stable type (Nominal operating power: 100mW) is available
• The use of twin crossbar contacts ensures high contact reliability
• Slim compact size 10.6 (L) 5.7 (W) 9.0 (H) mm
• Outstanding surge resistance

Applications:-

• Security Equipment
• Telephonic Equipment
• Electronic Consumer and Audio Visual Equipment
• Telecommunications Equipment
• Test and Measurement Equipment

Features :-

• Meets FCC Part 68 and Telcordia 2.5 kV surge withstand
• Low power consumption of 140 mW (Non-latching)
• High dielectric withstand voltage of 2, 000 VAC between coil and contacts (standard type); 1, 500 VAC between contacts of different polarity
• Tape and reel or tube packaging.
• Available in through-hole and SMT terminals

Features :-

• Low power consumption of 140 mW
• High dielectric withstand voltage of 2, 000 VAC between coil and contacts (standard type); 1, 500 VAC between contacts of different polarity
• Available in through-hole and SMT terminals.
• Meets FCC Part 68 and Telcordia 2.5 kV surge withstand.
• Tape and reel or tube packaging
• Standard models conform to UL/CSA standards. BSI (EN60950) certified models available (-Y versions)

Applications :-

• Telecommunication equipment
• Audio-visual products
• Industrial equipment
• Building automation equipment

Features :-

• Widening scope of application with multicontact latching
• Breakthrough height of 9.8 mm
• Gold-clad twin contacts ensure high reliability
• Suitable for use in difficult environments
• DIL terminal array enables use of IC sockets

Features :-

• DIL terminal array enables use of IC sockets
• Breakthrough height of 9.8 mm
• Gold-clad twin contacts ensure high reliability
• Polarized magnetic circuits realize resistance to shock and vibration
• Suitable for use in difficult environments

Applications :-

• Industrial equipment.
• Telecommunications
• Office equipment
• Business devices
• Audio systems

2 Amp DPDT(2 Form C) 9Vdc Signal Relay - TQ2-9Vdc

Features :-

• DIL terminal array enables use of IC sockets
• Flat compact size 14.0 (L) 9.0 (W) 5.0 (H) mm
• Self-clinching terminal also available
• Low thermal electromotive force
• Nominal operating power: High sensitivity of 140mW (2 Form C single side stable type)
• Latching types also available

Applications:-

• Communications
• OA equipment
• Measurement equipment
• Telephone-related equipment
• Industrial machines

10 Amp 12Vdc SPDT Automotive Relays - JSM1-12V-4 Automotive Power Relays

Features :-

• Sealed Construction
• Global Standard terminal pitch
• Low pick up voltage for high ambient
• Usable at high temperature :85 c

Applications :-

• Power Window
• Interior Lighting
• Car Stereo
• Power Seat
• Lift Gate

Features :-

• Low pick up voltage for high ambient use
• Usable at high temperature :85c
• Sealed Construction
• Global standard terminal pitch

Applications :-

• Car Stereo
• Power Window
• Lift Gate
• Door Lock
• Interior Lighting

Features :-

• Compact and high-capacity 25 A load switching
• Environmental protection specifications
• Pin in Paste* compatible model added
• It is extremely compact at approx. 2/3 the size of previous products

Applications :-

• Automatic door locks
• Powered seats
• Smart J/B related products
• Powered windows
• Electrically powered mirrors

Features :-

• Capable of 25A high-capacity load switching with compact size
• Terminal layout for simplifying PC board pattern design
• Plastic sealed type

Applications:-

• Power sunroof
• Slide door closers (for DC motor forward/reverse control circuits)
• Auto door lock
• Electrically powered mirrors
• Lift gates
• Power windows

1AMP 5VDCDPDT (2 Form C)High Frequency / RF Relays G6K-2F-RF-DC5

Features:-

Surface-mounting, 1-GHz-Band/ 3-GHz-Band, Miniature, DPDT,

• High-frequency Relay
• Miniaturized to 10.3 6.9 5.4 mm (L W H).
• Rated power consumption of 100 mW with high sensitivity
• Single-side stable and single-winding latching models are
• available.
• G6K(U)-2F-RF-T models for 3-GHz band join the lineup with a
• downsized footprint.
• New PCB terminals models are available.
• Models with a smaller footprint (G6K(U)-2F-RF-S) are available
• to help save space.

Applications:-

• Communications equipment
• Broadcasting and audio-visual equipment
• Test & measurement equipment

900 mA 600VAC CROSS PCB SSR-AQH2223 Solid State Relays

Features :-

• Supports 0.3 A, 0.6 A, 0.9 A and 1.2 A ON-state RMS currents.
• The 1.2 A type saves space with a DIP 8-pin package.
• Handles both 100 and 200 V AC loads
• High dielectric strength: 5, 000 V AC
• Two types available: Zero-cross type and Random type

*Features :-

• Controls low-level analog signals
• Low-level off state leakage current of max. 1 A
• Low on-resistance (Typ. 26) for normally-closed type
• High sensitivity and low onresistance

*Applications :-

• Telephone equipment (Dial pulse
• Security equipment
• Measuring instruments

0.5 Amp 400 Vdc SPST(1 Form A)PCB MountPanasonic Solid State Relays - AQZ204

Features :-

• Low-level off state leakage current of max. 10 A
• Eliminates the need for a power supply to drive the power MOSFET
• Slim SIL4-pin package (W) 3.5 (D) 21.0 (H) 12.5 mm
• Control low-level signal
• Extremely low on-resistance

Applications :-

• Measuring instruments
• Traffic signals
• Industrial machines

Features :-

• Controlled with low-level input signals
• Wide variation of 40V, 60V, 250V, 400V load voltage
• Controls low-level analog signals
• AC/DC dual use type and DC only type available.

Applications :-

• Data communication equipment
• High-speed inspection machines
• Computers
• High-speed inspection machines

Features :-

• Labor Saving (tab terminal)
• Compact Size W 28 L 38 H 30 mm
• Output arrangement 1a and 1a 2 available in the heat sink combined type
• Reverse input connection prevention function
• Heat sink combined types ready to mount on DIN rail added

• Mounting pitch 47.5mm
• With LED indication for operation status verification
• Compact Size W 40 X L 58 X H 25.5mm
• With terminal cover for safety
• Built in varistor for excellent surge absorption

Applications:-

• Heater Control
• Business Use: Cooking machine , Vending machine
• Industrial Use: Moulding Machine, Packing Machine

Features :-

• Labor Saving (tab terminal)
• Built-in varistor
• Output arrangement 1a and 1a 2 available in the heat sink combined type
• Compact Size W 28 L 38 H 30 mm
• Reverse input connection prevention function

Applications :-

• Vending machine
• Amusement machine
• Kitchen appliances
• Injection molding machine
• Packing machine

Features :-

• Superior anti-vibration and anti shock characterstics
• 10A high capacity realized for PC board terminal
• Vertical types with SIL terminal arrangement and flat types are available
• Reduced Noise generation
• VDE reinforced insulation compliant

Applications:-

• Traffic signal control
• Computer peripherals
• Packing Machines
• NC machnines
• Printing Machines
