Das & Company I Electrical Control Panels Manufacturers

Tangra, Kolkata, West Bengal

offers feeder piller panel. application : protection and control of power distribution (for outdoor use) ac rating volts : 0 – 500v ac rating amps : 100 – 1000a ac rating frequency : 50hz rated insulation voltage : 690v temp. rise : up to 35c rise over 50c ambient. degree of protection : ip 52, 54, 55, 65 power bus. bar : al or cu. bas bar over current protection : properly panel cote : 7 tank powder coated paint and as per client’s requirement. panel mount : floor / ground mounted, wall mounted, mounted on angle frame. current monitoring : possible phase monitoring : possible configuration : based on customer’s requirement. type test performed : short circuit with stand temp. rise with stand, degree of protection. product warranty : at list 12 month.

We are offering apfc panel. Application : improvement of power factor in the system ac rating volts : 0 – 800v ac rating amps : 100 – 1000a ac rating frequency : 50hz rated insulation voltage : 690v temp. Rise : up to 35c rise over 50c ambient. degree of protection : ip 52, 54, 55, 65 power bus. Bar : al or cu. Bas bar over current protection : properly panel cote : 7 tank powder coated paint and as per client’s requirement. panel mount : floor / ground mounted, wall mounted, mounted on angle frame. current monitoring : possible phase monitoring : possible configuration : based on customer’s requirement. type test performed : short circuit with stand temp. Rise with stand, degree of protection. product warranty : at list 12 month.
