the gear pump are based on the proven rotary trochoidal design – gerotor principal. these pumps are designed to meet specific demands of oem’s. the performance of the gear pump makes them an ideal choice for various industrial applications. special executions :

• specially coated internals for pumping of non –lubricating liquids.
• engineering plastics rotor set for chemicals & low viscosity fluids
• specially designed pumps for vacuum duty applications
• uni-directional

advantages of gear pump :

• single shaft – well supported at both ends
• high suction lift and low noise level as well as vibrations
• high volumetric and overall efficiency
• continuous, pulsation free flow due to axial entry in pumping element
• compact and light – weight design
• ease of assembling and dismantling without disturbing the pipeline.
• choice of oil seal / mechanical seal / gland pack.
• parts / pumps interchangeable with well known brands.

typical application ::

• transfer from tank to tank
• emptying of barrels
• lubricating and cooling of bearings , gears, mechanical seals and machine tools
• fuel oil booster

liquids handled :

• fuel oil
• lube oil
• neutral liquids with lubricating properties

Applications : The main components which characterize the pump are a metallic single helical rotary part ROTOR and fixed double helical resilient polymer part STATOR in which the rotor turns and thereby a complex progressive sealing line (cspl) is maintanined. Whilst the rotor rotates inside the stator, the cavities formed between them progresses from suction to discharge end, gently carrying the media.

Drive Arrangements :

• DIRECT drive lectric motor, geared motor, gear box, Mechanical Speed Variator, Eddy Current DC Drive, Hydraulic, Pneumatic, Petrol & Diesesl Engines.
• For accurate and variable flow rates, AC Variable frequenc Drives can be used.

Material Options :

• Housing Parts : AISI304, AISI316, AISI316L
• Rotor & Shaft : AISI304, AISI316, AISI316L
• Stator : NBR, HNBR, EPDM, CSM, Q

White, food grade, abrasion resistant & high temperature resistant variants.

Pumps are single suction multistage segment centrifugal pumps which adopt energy-efficient hydraulic model, confirm to centrifugal pump technical condition with wide performance range, high efficiency, reasonable structure , safe and steady operation, low noise, long life performance, easy installation and maintenance.

Applications :

• Irrigation – Sprinkler Installations
• Water Supply
• Pressure Boosting – Multi stories buildings,
• Hydro – Pneumatic
• Water Works Fire Fighting – Mining wash down Applications
• Hydraulic press / Circuits transfer & circulation hot & cold water
• Boiler feed pumps – Condensate pumps

Application : These pumps are made with flame proof / explosion proof motor these pumps are self priming type, centrifugal type, vertical sump pumps type, mud pump type, gear type, multistage pump type, or any other type pump can be made as per requirement of customer. These pumps are widely used to handle petrol, kerosene, diesel, oil and solvents handling. Motors can be available with CMRI & DGMS certificate on request material of pumps & sealing arrangement can be made as per customer requirements or as per material to be handled.

We are a chief Manufacturer, Exporter and Importer of the premium quality Chemical Process Pump. We offer a great range of Chemical Process Pump to our clients. Our Chemical Process Pump is known for its durability, high performance and strength. Our Chemical Process Pump are available at really competitive prices.

Features :

• More than 3mm corrosion allowance (cast iron) for extended use on corrosive applications
• Chemical Process Pump construction allows rotating assembly to be with drawn without disturbing the suction and delivery connections
• One piece self vanted foot mounted, center suction volute casting, single stage, closed / semi open dynamically balanced impeller
• Flange drilling standards as per DIN 24255 / ISO 2858 or as per customer's requirement
• Designed for 16 bar working pressure with optional casing for a working pressure of up to 20 bars
• A robust and solid construction that guarantees long life even under high suction pressure conditions
• Heavy-duty, deep-grooved bearings with minimum 50, 000 hours operating life under normal condition. (Grease lubricated, oil lubrication available on request)
• Heavy-duty, stiff solid shaft design with low L3/D4 ratio ensures less than 0.05mm shaft deflection at the seal face in all operating condition. This extends the seal life
• Seal housing is constructed to accommodate different seal/gland designs, so as to meet the severe heavy-duty requirements. ( standard is gland packing , seal version on special request)
• Excellent parts interchangeability reduces inventory levels for spare parts to a minimum
• Special design for high temperature thermic fluid available in request
• Motor or engine driven sets
• Special monoblock versions available on request

Applications :

• For pumping clear/turbid water/chemicals & volatile liquids
• Air conditional plants
• Power station
• Mine drainage
• Sprinkler systems fire fighting
• Booster service
• Oils
• Brine

TECHNICAL SPECIFICATION 2  :- ( PP Rotary Hand Operated Barrel pump)

Type                      :- PP Vertical Mannual hand operated barrel pump.

Pump Make           :- “Malhar”

Pump Model          :- RHB-PP-1

Pump inlet             :- 1”

Capacity               :-  250 ml/Rotation

Pipe tube length     :- 990 mm

These pumps are made with flame proof / explosion proof motor these pumps are self priming type, centrifugal type, vertical sump pumps type, mud pump type, gear type, multistage pump type, or any other type pump can be made as per requirement of customer. These pumps are widely used to handle petrol, kerosene, diesel, oil and solvents handling. Motors can be available with CMRI & DGMS certificate on request material of pumps & sealing arrangement can be made as per customer requirements or as per material to be handled.

The VAF is a combination of vertical high efficiency & axial flow impeller pump . We have a complete range of this type of pumps which are suited for applications that require large quantities of flow with low head.

Applications :

• Flood Control
• Water Treatment
• Shipping
• Ground Water Development and Irrigation
• Cooling Water (power)
• Dewatering and Water Supply (mining)
• Agriculture

Vertical Sump Pump can be used in any installation or specially where the saving of space is important factor and most important where liquid is difficult to lift because of nature like temp, corrosiveness etc. These pump are designed for use where the liquid handled to be is of highly corrosive. Nature or where non - adherence of product or zero metallic contamination is must. These pumps are equally ideal for continuous or intermittent service for handling Corrosive as well as ultra pure chemicals without fear of corrosion or contamination. High Temperature services : Maximum working temperature is 110 C / 200 C. Length : Pumps lengths available from 1 to 12 with flow rate up to 50m3/h or 120 meter head. Higher capacities and head available on request and even multistage pump can be also made. Models : Available in conventional or tailor-made configuration. Several models such as suction extension with float switch, duplex pumping station with float switch (auto on/off device) also available.

Application Fields :These pumps are in extensive use in the fields of :

• Pollution Control
• Filtration
• Transferring Corrosive Chemicals
• Slurries
• Bio gas plants
• Sewage
• Waste water treatment plant
• Phosphoric Acid Plant. H, PO, H2SIFs, H2SO4, HF And
• Their Mixtures
• Gas washing plant
• Scrubbed liquids containing, F, CL, SO2, Ammonia
• Water treatment plant
• Any types of acidic water lifting
• M.S Vertical pump are used for transfer of sulphuric acid 98 %. OLUM, CLOTO, NEPTHA

Few words that better describe our Vertical Single Stage Centrifugal Pump are sturdy construction and longer functional life. We are named among the renowned Manufacturers, Exporters and Suppliers of Single Stage Centrifugal Pump. As its manufacturing is done using the latest techniques by following the set industry standards, our Single Stage Centrifugal Pump is the perfect choice. If interested in buying Single Stage Centrifugal Pump, count on us.

Pump Design :

• The pumps are primarily designed to handle water and are suitable for handling water in water supply systems for domestic and industrial use.

• Single stage pumping units of compact design with back pullout feature with suction & discharge flange arranged in-line opposite one another for direct installation in the pipeline.

• Motor and pump are close coupled by rigid coupling.

• The completer rotating portion can be removed without disconnecting the pump casing from the connecting pipe line.

Applications :

• Water SupplySystems

• Water circulation /Transfer

• Hot waterCirculation

• Agriculture

• Industry

• Ship Building

• Cooling Towers

• And many otherApplications

Design Details :

• Direction of Rotation : Clock wise looking from the motor end at the pump.

• Shaft Sealing : The Shaft is sealed by means of a Mechanical seal.

• Wearing Ring : Every Volute Casing is fitted with a Replaceable wearing ring.

• Casing Gasket : The Volute casing is sealed be means of a flat gasket

To Transfer Highly Viscous Materials such as Petroleum Jelly, Adhesives, Creams, Pastes from Barrels & Liquid Glucose.

Features :

• Made from Cast Iron / ss as per customers requirement.
• Work in any position Vertical / Horizontal Upside down
• Very Easy Installation
• Made from 4 parts only
• Liquid of any viscosity can be used
• Diaphragm is of PTFE Material

Applications

To Transfer Highly Viscous Materials such as Petroleum Jelly, Adhesives, Creams, Pastes from Barrels & Liquid Glucose.

Our organization is avidly engaged in supplying an exclusive range of Vertical Sealless Glandless Pump at reasonable prices. For the convenience of the clients, we facilitate them with several payment procedures including both online and offline. In addition to this, we guarantee for authentication and confidentiality.
