Spring Seals in Ahmedabad

• MOQ : 5 Piece
• Material Grade : SS304
• Pressure (Bar) : 20 Bar
• Type : Mud pump
• Warranty : 1 Year
• Supply Type : Manufacturer
• Working Temperature : 60-260
• Color : Silver
• Material : CI,SS304,SS316
• Packaging Type : Carton Box

Applications   In fertilizers   For the corrosive liquids   For the acid pumps   For chemical industry   For petrochemical industry   For the sewage more...

• Thickness : 40-50mm
• Sealing Type : Mechanical
• Temperature Range Deg C : -60-180
• Pump RPM [Speed] : 2900rpm /1440rpm
• Country of Origin : India
• Material : SS
• Supply Type : Manufacturer
• Inner Diameter : 50mm
• Type : Mud pump
• Certification : ISO 9001- 2015

- Circulation Pumps For Central Heating. - Water Pumps - Sewage & Submersible Pumps - Chemical Process Pumps   - Shaft Diameter : (10 mm to 100 mm) (0.5" to 4.0") - Pressure : 10 Bar (kg/cm ) - Temperature : -60 c to 180 c - Shaft Speed : Upto 6000 RPM According to Shaft Size & Pressure. more...

• Working Temperature : 60-260
• Size : 2Inch
• Inner Diameter : 50mm
• Thickness : 40-50mm
• Material : SS
• Warranty : 1 Year
• Temperature Range Deg C : 60-260
• Supply Type : Manufacturer
• Pressure (Bar) : 20 Bar
• Color : Silver

 Face Materials : (Dynamic Ring & Stationary Ring ) Carbon, Ceramic (99.5%). Silicon Carbide, Tungsten Carbide, Chrome Cast Steel & Which Are Suitable For Fluid.  Secondary Seal : U81 & B81 : Viton, EPDM, Silicon, Aflas, EPR, Kalrez, TCV. U86 & B86 : GFT, PTFE, FEP, Grafoil.  Hardware : SS 316, SS 304, more...

• MOQ : 10 Piece
• Temperature : -20 Deg to 200 Deg C
• Pressure : 14 Bar (Max.)
• Supply Type : Manufacturer
• Application : Oil & Gas Industries
• Color : Silver
• Brand Name : Hexoto
• Shape : Round
• Material : Metal
• Velocity : 20 m/sec

more...

• Pressure : 14 Bar (Max.)
• Brand Name : Hexoto
• Temperature : -20 Inch to 200 Inch C
• Finishing : Polished
• Packaging Type : Carton Box
• Material : SS
• Velocity : 20 m/sec
• Supply Type : Manufacturer
• Usage : Oil & Gas Industries

more...

• Brand Name : Hexoto
• Velocity : 20 m/sec
• Temperature : -20 Deg to 200 Deg C
• Pressure : 14 Bar (Max.)
• Color : Silver
• Country of Origin : India
• Usage : Oil & Gas Industries
• Material : Steel
• Supply Type : Manufacturer

Seal Characteristics: Single acting Unbalanced Inside mounted Single helical coil spring Indeendent of direction of rotation more...

• Seal face : Special cast steel, Silicon carbide , Ceramic
• Seat : Carbon, Silicon carbide*, Ceramic, Special steel.
• Secondary seals : EPDM, NBR, FKM, FFKM, PTFE.

Features For plain shafts Single seal Unbalanced Rotating conical spring Dependent on direction of rotation Operating Range Shaft diameter: d1 = upto 80 mm Pressure: p1 = 12 bar Temperature: t = -20 °C to +140 °C Sliding velocity: vg = 15 m/s   Advantages Universal application opportunities Insensitive to more...

• Seal face : Carbon,Silicon carbide,Tungsten carbide
•   : Seat
• Secondary Seal : VITON,PTFE, GFT, TTV, EPDM, NBR (O-ring will be used for clean media application and wedges be used for corrosive media application )
• d1 = 100 mm : Pressure
• Silicon carbide,Tungsten carbide, Ceramic :
• t = -20 °C to 200 °C : Sliding velocity
• p1 = 12 bar : Temperature

Features Unbalanced Available in single seal and dual seal For plain shaft Rotating multiple spring Independent of direction of rotation Advantages Flexibility in torque transmission Optimized, narrow width seal face design Compact axial and radial dimensions Recommended applications Process industry Chemical more...

• Seat G13 : Carbon
• Seal face : Special cast steel, Silicon carbide , Ceramic
• Seat G4 & G6 : Silicon carbide
• Secondary seals : EPDM, NBR, FKM, FFKM
• SeatG9 : Carbon,Silicon carbide

Features For plain shafts Single seal Unbalanced Wave spring or multiple springs rotating Independent of direction of rotation Variant With PTFE secondary seals for high chemical resistance Operating Range Shaft diameter: d1 = 14 ... 100 mm Pressure: p1 = 20 bar Temperature: t = -40 °C to +200 °C Sliding ve more...

• Operating Condition : Size dl: 12....100 mm Temperature:-20 C To + 280 C  Pressure: 12 Bar (Max.) Velocity v: 20m/sec. Speed: 4000 RPM
• Face Martial : Silicon Carbide, Tungsten Carbide, Carbon, Ceramic
• Metal Parts : SS 316, SS 304
• Usage : Crystallizing, Slurry, Suspended Solids Slurry Saturated Chemical Slurry, Solvent, And Paper & Pulp Industries.
• Secondry Seal : Nitrile, Viton, EPDM, PTFE, TTV

SI-301 SPO Type Seal Are Single Coil Spring Unbalanced Seal Develop For Dirty Media & Mild Slurry. This Seal More Suitable For Application Where Crystallizing Solution Are Handled. Due To Its Unique Positive Drive Lug Its Direction Rotates Independently. It Is Simple In Construction And Easy To Install. more...

• Usage : Petrochemicals, petroleum Refinery, Solvents, Hydrocarbons & General Industrial Fluids.
• Face Martial : Silicon Carbide, Tungsten Carbide, Carbon, Ceramic
• Metal Parts : SS316,SS304
• Secondry Seal : Nitrile, Viton, EPDM, PTFE, TTV
• Operating Condition : Size dl: 12 .... 100 mm Temperature: -60 C To + 200 C  Pressure: 10 Bar (Max.) Velocity v: 20m/Sec. Speed: 4500 RPM

SI-501 M Seal Has Been Designed & Developed For Universal Application Its Compact Design Permits The Uses In The Standard Stuffing Boxes On Centrifugal Pumps.Seal Are Designed To Handle Clear Liquids Under Normal Pv Condition. These Seal Required Lower Stuffing Box For Installation. more...

• Usage : Water pumps, Circulation Pump For Central Heating, Chemical Process Pump, Sewage pumps.
• Secondry Seal : Nitrile, Viton, PTFE, TTV, EPDM
• Face Martial : Silicon Carbide, Tungsten Carbide, Carbon, Ceramic
• Metal Parts : SS 316, SS 304
• Operating Condition : Size dl: 12....80 mm Temperature: -20 C To + 120 C  Pressure: 8 Bar (Max.) Velocity v: 20m/Sec. Speed: 4000 RPM

SI-401 CON Conical Spring Seal Are Extremely Sharp And Reliable, Therefore ItIs Used For Various Sealing Applications. This Type Seal Are Loaded With Various Combination Of Face Such As Solid Carbon And Shrink Fitted. more...

We are a major  Single Spring Mechanical Seal  Manufacturer and Exporter from Ahmedabad (India). Our Single Spring Mechanical Seal is known for its superior make and durability more...

We are a prominent  Balance and Unbalance Single Spring Seal Manufacturer and Exporter from India. Our Balance and Unbalance Single Spring Seal is renowned for its excellent service. more...

  We are popular as a trustworthy  Conical Single Spring Seal  Manufacturer and Exporter from India. Our Conical Single Spring Seal is made from high quality raw material that ensures excellent durability. The Conical Single Spring Seal is known for its easy to install feature. more...

• Supply Type : Manufacturer

We are a major Single Spring Mechanical Seal Manufacturer and Exporter. Our Single Spring Mechanical Seal is known for its superior make and durability. more...

• Supply Type : Manufacturer

We are popular as a trustworthy Conical Single Spring Seal Manufacturer and Exporter from India. Our Conical Single Spring Seal is made from high quality raw material that ensures excellent durability. more...

Daemar offers a full range of Single Spring "Pusher" Mechanical Seals. Including the standard Types A, B, C, D and E. Which are equivalent to type 6, 6A, 21, 2, 1. more...

Daemar delivers a range of Mechanical Seal solutions from the standard Types A, B, C, D and E.  Daemar can also supply custom seals such as our new Type W Axial Shaft Seal. more...

We offer the metal single spring seal manufactured from finest quality of raw material. It is easy to operate and simple to install seal. It is specially designed to handle the fluids like slurries and sludge. It is widely used in the sewage. The seals are popular for the tolerance. metal single spring seal i more...

A Single spring seal is used to handle the fluids like gunk and muck. Single spring seal is used in different companies for different operation related to sludge and water. With the help of this seal a pump can transfer sludge and water with no any leakage. We construct the seals with a large variety of suita more...

We manufacture, supply and export the finest quality of single coil spring seals, for various industrial applications. The single coil spring seals are used mainly in dirty and congealing application. The seals are highly demanded for the anti abrasive applications. We have designed the U71 and U76 series and more...

Single Coil Spring Seals: custom design single coil spring seals at globe seal. We are prime manufacturer & supplier of single coil spring seals in India. We provide the specially designed GSS – 151 and GSS – 156 series of seals for the various industrial applications. It is an internal mounted unbalanced more...

The Globe Star Engineers, Ahmedabad, Gujarat manufacture, supply and export the precisely engineered, strong and sturdy wave spring seals. It’s a helical compression springs. The wave spring seal has the multiple applications for the various industries. The wave spring seals are very useful in handling the more...
